Embedding Jetty
Previous  Chapter 26. Embedding
Home		  Next
Contact the core Jetty developers at www.webtide.com

private support for your internal/customer projects ... custom extensions and distributions ... versioned snapshots for indefinite support ... scalability guidance for your apps and Ajax/Comet projects ... development services from 1 day to full product delivery

Embedding Jetty

Jetty has a slogan, "Don't deploy your application in Jetty, deploy Jetty in your application!" What this means is that as an alternative to bundling your application as a standard WAR to be deployed in Jetty, Jetty is designed to be a software component that can be instantiated and used in a Java program just like any POJO. Put another way, running Jetty in embedded mode means putting an HTTP module into your application, rather than putting your application into an HTTP server.

This tutorial takes you step-by-step from the simplest Jetty server instantiation to running multiple web applications with standards-based deployment descriptors. The source for most of these examples is part of the standard Jetty project.

Overview

To embed a Jetty server the following steps are typical and are illustrated by the examples in this tutorial:

  1. Create a Server instance.

  2. Add/Configure Connectors.

  3. Add/Configure Handlers and/or Contexts and/or Servlets.

  4. Start the Server.

  5. Wait on the server or do something else with your thread.

Creating the Server

The following code from SimplestServer.java instantiates and runs the simplest possible Jetty server:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
//
//  ========================================================================
//  Copyright (c) 1995-2014 Mort Bay Consulting Pty. Ltd.
//  ------------------------------------------------------------------------
//  All rights reserved. This program and the accompanying materials
//  are made available under the terms of the Eclipse Public License v1.0
//  and Apache License v2.0 which accompanies this distribution.
//
//      The Eclipse Public License is available at
//
//      The Apache License v2.0 is available at
//
//  You may elect to redistribute this code under either of these licenses.
//  ========================================================================
//

package org.eclipse.jetty.embedded;

import org.eclipse.jetty.server.Server;

/* ------------------------------------------------------------ */
/** The simplest possible Jetty server.
 */
public class SimplestServer
{
    public static void main(String[] args) throws Exception
    {
        Server server = new Server(8080);
        server.start();
        server.dumpStdErr();
        server.join();
    }
}

This runs an HTTP server on port 8080. It is not a very useful server as it has no handlers, and thus returns a 404 error for every request.

Using Handlers

To produce a response to a request, Jetty requires that you set a Handler on the server. A handler may:

  • Examine/modify the HTTP request.

  • Generate the complete HTTP response.

  • Call another Handler (see HandlerWrapper).

  • Select one or many Handlers to call (see HandlerCollection).

HelloWorld Handler

The following code based on HelloHandler.java shows a simple hello world handler:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
//
//  ========================================================================
//  Copyright (c) 1995-2014 Mort Bay Consulting Pty. Ltd.
//  ------------------------------------------------------------------------
//  All rights reserved. This program and the accompanying materials
//  are made available under the terms of the Eclipse Public License v1.0
//  and Apache License v2.0 which accompanies this distribution.
//
//      The Eclipse Public License is available at
//
//      The Apache License v2.0 is available at
//
//  You may elect to redistribute this code under either of these licenses.
//  ========================================================================
//

package org.eclipse.jetty.embedded;

import java.io.IOException;

import javax.servlet.ServletException;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;

import org.eclipse.jetty.server.Request;
import org.eclipse.jetty.server.handler.AbstractHandler;

public class HelloHandler extends AbstractHandler
{
    final String _greeting;
    final String _body;

    public HelloHandler()
    {
        _greeting="Hello World";
        _body=null;
    }

    public HelloHandler(String greeting)
    {
        _greeting=greeting;
        _body=null;
    }

    public HelloHandler(String greeting,String body)
    {
        _greeting=greeting;
        _body=body;
    }

    public void handle(String target, Request baseRequest, HttpServletRequest request, HttpServletResponse response) throws IOException, ServletException
    {
        response.setContentType("text/html;charset=utf-8");
        response.setStatus(HttpServletResponse.SC_OK);
        baseRequest.setHandled(true);

        response.getWriter().println("<h1>"+_greeting+"</h1>");
        if (_body!=null)
            response.getWriter().println(_body);
    }
}

The parameters passed to the handle method are:

  • target–the target of the request, which is either a URI or a name from a named dispatcher.

  • baseRequest–the Jetty mutable request object, which is always unwrapped.

  • request–the immutable request object, which may have been wrapped by a filter or servlet.

  • response–the response, which may have been wrapped by a filter or servlet.

The handler sets the response status, content-type, and marks the request as handled before it generates the body of the response using a writer.

Running HelloWorldHandler

To allow a Handler to handle HTTP requests, you must add it to a Server instance. The following code from OneHandler.java shows how a Jetty server can use the HelloWorld handler:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
//
//  ========================================================================
//  Copyright (c) 1995-2014 Mort Bay Consulting Pty. Ltd.
//  ------------------------------------------------------------------------
//  All rights reserved. This program and the accompanying materials
//  are made available under the terms of the Eclipse Public License v1.0
//  and Apache License v2.0 which accompanies this distribution.
//
//      The Eclipse Public License is available at
//
//      The Apache License v2.0 is available at
//
//  You may elect to redistribute this code under either of these licenses.
//  ========================================================================
//

package org.eclipse.jetty.embedded;

import org.eclipse.jetty.server.Server;

public class OneHandler
{
    public static void main(String[] args) throws Exception
    {
        Server server = new Server(8080);
        server.setHandler(new HelloHandler());

        server.start();
        server.join();
    }
}

One or more handlers do all request handling in Jetty. Some handlers select other specific handlers (for example, a ContextHandlerCollection uses the context path to select a ContextHandler); others use application logic to generate a response (for example, the ServletHandler passes the request to an application Servlet), while others do tasks unrelated to generating the response (for example, RequestLogHandler or StatisticsHandler).

Later sections describe how you can combine handlers like aspects. You can see some of the handlers available in Jetty in theorg.eclipse.jetty.server.handler package.

Handler Collections and Wrappers

Complex request handling is typically built from multiple Handlers that you can combine in various ways. Jetty has several implementations of the HandlerContainer interface:

HandlerCollection

Holds a collection of other handlers and calls each handler in order. This is useful for combining statistics and logging handlers with the handler that generates the response.

HandlerList

A Handler Collection that calls each handler in turn until either an exception is thrown, the response is committed or the request.isHandled() returns true. You can use it to combine handlers that conditionally handle a request, such as calling multiple contexts until one matches a virtual host.

HandlerWrapper

A Handler base class that you can use to daisy chain handlers together in the style of aspect-oriented programming. For example, a standard web application is implemented by a chain of a context, session, security and servlet handlers.

ContextHandlerCollection

A specialized HandlerCollection that uses the longest prefix of the request URI (the contextPath) to select a contained ContextHandler to handle the request.

Scoped Handlers

Much of the standard Servlet container in Jetty is implemented with HandlerWrappers that daisy chain handlers together: ContextHandler to SessionHandler to SecurityHandler to ServletHandler. However, because of the nature of the servlet specification, this chaining cannot be a pure nesting of handlers as the outer handlers sometimes need information that the inner handlers process. For example, when a ContextHandler calls some application listeners to inform them of a request entering the context, it must already know which servlet the ServletHandler will dispatch the request to so that the servletPath method returns the correct value.

The HandlerWrapper is specialized to the ScopedHandler abstract class, which supports a daisy chain of scopes. For example if a ServletHandler is nested withing a ContextHandler, the order and nesting of execution of methods is:

Server.handle(...)
  ContextHandler.doScope(...)
    ServletHandler.doScope(...)
      ContextHandler.doHandle(...)
        ServletHandler.doHandle(...)
          SomeServlet.service(...)

Thus when the ContextHandler handles the request, it does so within the scope the ServletHandler has established.

Resource Handler

The FileServer example shows how you can use a ResourceHandler to serve static content from the current working directory:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
//
//  ========================================================================
//  Copyright (c) 1995-2014 Mort Bay Consulting Pty. Ltd.
//  ------------------------------------------------------------------------
//  All rights reserved. This program and the accompanying materials
//  are made available under the terms of the Eclipse Public License v1.0
//  and Apache License v2.0 which accompanies this distribution.
//
//      The Eclipse Public License is available at
//
//      The Apache License v2.0 is available at
//
//  You may elect to redistribute this code under either of these licenses.
//  ========================================================================
//

package org.eclipse.jetty.embedded;

import org.eclipse.jetty.server.Handler;
import org.eclipse.jetty.server.Server;
import org.eclipse.jetty.server.handler.DefaultHandler;
import org.eclipse.jetty.server.handler.HandlerList;
import org.eclipse.jetty.server.handler.ResourceHandler;

/* ------------------------------------------------------------ */
/** Simple Jetty FileServer.
 * This is a simple example of Jetty configured as a FileServer.
 */
public class FileServer
{
    public static void main(String[] args) throws Exception
    {
        // Create a basic Jetty server object that will listen on port 8080.  Note that if you set this to port 0
        // then a randomly available port will be assigned that you can either look in the logs for the port,
        // or programmatically obtain it for use in test cases.
        Server server = new Server(8080);

        // Create the ResourceHandler. It is the object that will actually handle the request for a given file. It is
        // a Jetty Handler object so it is suitable for chaining with other handlers as you will see in other examples.
        ResourceHandler resource_handler = new ResourceHandler();
        // Configure the ResourceHandler. Setting the resource base indicates where the files should be served out of.
        // In this example it is the current directory but it can be configured to anything that the jvm has access to.
        resource_handler.setDirectoriesListed(true);
        resource_handler.setWelcomeFiles(new String[]{ "index.html" });
        resource_handler.setResourceBase(".");

        // Add the ResourceHandler to the server.
        HandlerList handlers = new HandlerList();
        handlers.setHandlers(new Handler[] { resource_handler, new DefaultHandler() });
        server.setHandler(handlers);

        // Start things up! By using the server.join() the server thread will join with the current thread.
        // See "http://docs.oracle.com/javase/1.5.0/docs/api/java/lang/Thread.html#join()" for more details.
        server.start();
        server.join();
    }

}

Notice that a HandlerList is used with the ResourceHandler and a DefaultHandler, so that the DefaultHandler generates a good 404 response for any requests that do not match a static resource.

Embedding Connectors

In the previous examples, the Server instance is passed a port number and it internally creates a default instance of a Connector that listens for requests on that port. However, often when embedding Jetty it is desirable to explicity instantiate and configure one or more Connectors for a Server instance.

One Connector

The following example, OneConnector.java, instantiates, configures, and adds a single HTTP connector instance to the server:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
//
//  ========================================================================
//  Copyright (c) 1995-2014 Mort Bay Consulting Pty. Ltd.
//  ------------------------------------------------------------------------
//  All rights reserved. This program and the accompanying materials
//  are made available under the terms of the Eclipse Public License v1.0
//  and Apache License v2.0 which accompanies this distribution.
//
//      The Eclipse Public License is available at
//
//      The Apache License v2.0 is available at
//
//  You may elect to redistribute this code under either of these licenses.
//  ========================================================================
//

package org.eclipse.jetty.embedded;

import org.eclipse.jetty.server.Server;
import org.eclipse.jetty.server.ServerConnector;

/* ------------------------------------------------------------ */
/**
 * A Jetty server with one connectors.
 */
public class OneConnector
{
    public static void main(String[] args) throws Exception
    {
        // The Server
        Server server = new Server();

        // HTTP connector
        ServerConnector http = new ServerConnector(server);
        http.setHost("localhost");
        http.setPort(8080);
        http.setIdleTimeout(30000);

        // Set the connector
        server.addConnector(http);

        // Set a handler
        server.setHandler(new HelloHandler());

        // Start the server
        server.start();
        server.join();
    }
}

In this example the connector handles the HTTP protocol, as that is the default for the ServerConnector class.

Many Connectors

When configuring multiple connectors (for example, HTTP and HTTPS), it may be desirable to share configuration of common parameters for HTTP. To achieve this you need to explicitly configure the ServerConnector class with ConnectionFactory instances, and provide them with common HTTP configuration.

The ManyConnectors example, configures a server with two ServerConnector instances: the http connector has a HTTPConnectionFactoryinstance; the https connector has a SslConnectionFactory chained to a HttpConnectionFactory. Both HttpConnectionFactories are configured based on the same HttpConfiguration instance, however the HTTPS factory uses a wrapped configuration so that a SecureRequestCustomizercan be added.

SPDY Connectors

The SPDYConnector example is a similar to the HTTPS connector except that the SslConnectionFactory is chained to the NPNConnectionFactory that negotiates whether the next protocol is to be SPDY/2, SPDY/3 or HTTPS.

Embedding Servlets

Servlets are the standard way to provide application logic that handles HTTP requests. Servlets are similar to a Jetty Handler except that the request object is not mutable and thus cannot be modified. Servlets are handled in Jetty by A ServletHandler. It uses standard path mappings to match a Servlet to a request; sets the requests servletPath and pathInfo; passes the request to the servlet, possibly via Filters to produce a response.

The MinimalServlets example creates a ServletHandler instance and configures a single HelloServlet:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
//
//  ========================================================================
//  Copyright (c) 1995-2014 Mort Bay Consulting Pty. Ltd.
//  ------------------------------------------------------------------------
//  All rights reserved. This program and the accompanying materials
//  are made available under the terms of the Eclipse Public License v1.0
//  and Apache License v2.0 which accompanies this distribution.
//
//      The Eclipse Public License is available at
//
//      The Apache License v2.0 is available at
//
//  You may elect to redistribute this code under either of these licenses.
//  ========================================================================
//

package org.eclipse.jetty.embedded;

import java.io.IOException;

import javax.servlet.ServletException;
import javax.servlet.http.HttpServlet;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;

import org.eclipse.jetty.server.Server;
import org.eclipse.jetty.servlet.ServletHandler;

public class MinimalServlets
{
    public static void main(String[] args) throws Exception
    {
        // Create a basic jetty server object that will listen on port 8080.  Note that if you set this to port 0
        // then a randomly available port will be assigned that you can either look in the logs for the port,
        // or programmatically obtain it for use in test cases.
        Server server = new Server(8080);

        // The ServletHandler is a dead simple way to create a context handler that is backed by an instance of a
        // Servlet.  This handler then needs to be registered with the Server object.
        ServletHandler handler = new ServletHandler();
        server.setHandler(handler);

        // Passing in the class for the servlet allows jetty to instantite an instance of that servlet and mount it
        // on a given context path.

        // !! This is a raw Servlet, not a servlet that has been configured through a web.xml or anything like that !!
        handler.addServletWithMapping(HelloServlet.class, "/*");

        // Start things up! By using the server.join() the server thread will join with the current thread.
        // See "http://docs.oracle.com/javase/1.5.0/docs/api/java/lang/Thread.html#join()" for more details.
        server.start();
        server.join();
    }

    @SuppressWarnings("serial")
    public static class HelloServlet extends HttpServlet
    {
        @Override
        protected void doGet(HttpServletRequest request, HttpServletResponse response) throws ServletException, IOException
        {
            response.setContentType("text/html");
            response.setStatus(HttpServletResponse.SC_OK);
            response.getWriter().println("<h1>Hello SimpleServlet</h1>");
        }
    }
}

Embedding Contexts

A ContextHandler is a ScopedHandler that responds only to requests that have a URI prefix that matches the configured context path. Requests that match the context path have their path methods updated accordingly and the contexts scope is available, which optionally may include:

  • A Classloader that is set as the Thread context classloader while request handling is in scope.

  • A set of attributes that is available via the ServletContext API.

  • A set of init parameters that is available via the ServletContext API.

  • A base Resource which is used as the document root for static resource requests via the ServletContext API.

  • A set of virtual host names.

The following OneContext example shows a context being established that wraps the HelloHandler:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
//
//  ========================================================================
//  Copyright (c) 1995-2014 Mort Bay Consulting Pty. Ltd.
//  ------------------------------------------------------------------------
//  All rights reserved. This program and the accompanying materials
//  are made available under the terms of the Eclipse Public License v1.0
//  and Apache License v2.0 which accompanies this distribution.
//
//      The Eclipse Public License is available at
//
//      The Apache License v2.0 is available at
//
//  You may elect to redistribute this code under either of these licenses.
//  ========================================================================
//

package org.eclipse.jetty.embedded;

import org.eclipse.jetty.server.Server;
import org.eclipse.jetty.server.handler.ContextHandler;

public class OneContext
{
    public static void main(String[] args) throws Exception
    {
        Server server = new Server(8080);

        ContextHandler context = new ContextHandler();
        context.setContextPath("/");
        context.setResourceBase(".");
        context.setClassLoader(Thread.currentThread().getContextClassLoader());
        context.setHandler(new HelloHandler());

        server.setHandler(context);

        server.start();
        server.join();
    }
}

When many contexts are present, you can embed a ContextHandlerCollection to efficiently examine a request URI to then select the matching ContextHandler(s) for the request. The ManyContexts example shows how many such contexts you can configure:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
//
//  ========================================================================
//  Copyright (c) 1995-2014 Mort Bay Consulting Pty. Ltd.
//  ------------------------------------------------------------------------
//  All rights reserved. This program and the accompanying materials
//  are made available under the terms of the Eclipse Public License v1.0
//  and Apache License v2.0 which accompanies this distribution.
//
//      The Eclipse Public License is available at
//
//      The Apache License v2.0 is available at
//
//  You may elect to redistribute this code under either of these licenses.
//  ========================================================================
//

package org.eclipse.jetty.embedded;

import org.eclipse.jetty.server.Handler;
import org.eclipse.jetty.server.Server;
import org.eclipse.jetty.server.handler.ContextHandler;
import org.eclipse.jetty.server.handler.ContextHandlerCollection;

public class ManyContexts
{
    public static void main(String[] args) throws Exception
    {
        Server server = new Server(8080);

        ContextHandler context = new ContextHandler("/");
        context.setContextPath("/");
        context.setHandler(new HelloHandler("Root Hello"));

        ContextHandler contextFR = new ContextHandler("/fr");
        contextFR.setHandler(new HelloHandler("Bonjoir"));

        ContextHandler contextIT = new ContextHandler("/it");
        contextIT.setHandler(new HelloHandler("Bongiorno"));

        ContextHandler contextV = new ContextHandler("/");
        contextV.setVirtualHosts(new String[]{ "127.0.0.2" });
        contextV.setHandler(new HelloHandler("Virtual Hello"));

        ContextHandlerCollection contexts = new ContextHandlerCollection();
        contexts.setHandlers(new Handler[] { context, contextFR, contextIT, contextV });

        server.setHandler(contexts);

        server.start();
        server.join();
    }
}

Embedding ServletContexts

A ServletContextHandler is a specialization of ContextHandler with support for standard sessions and Servlets. The following OneServletContext example instantiates a DefaultServlet to server static content from /tmp/ and a DumpServlet that creates a session and dumps basic details about the request:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
//
//  ========================================================================
//  Copyright (c) 1995-2014 Mort Bay Consulting Pty. Ltd.
//  ------------------------------------------------------------------------
//  All rights reserved. This program and the accompanying materials
//  are made available under the terms of the Eclipse Public License v1.0
//  and Apache License v2.0 which accompanies this distribution.
//
//      The Eclipse Public License is available at
//
//      The Apache License v2.0 is available at
//
//  You may elect to redistribute this code under either of these licenses.
//  ========================================================================
//

package org.eclipse.jetty.embedded;

import org.eclipse.jetty.server.Server;
import org.eclipse.jetty.servlet.ServletContextHandler;
import org.eclipse.jetty.servlet.ServletHolder;

public class OneServletContext
{
    public static void main(String[] args) throws Exception
    {
        Server server = new Server(8080);

        ServletContextHandler context = new ServletContextHandler(ServletContextHandler.SESSIONS);
        context.setContextPath("/");
        server.setHandler(context);

        context.addServlet(org.eclipse.jetty.servlet.DefaultServlet.class,"/");
        context.addServlet(new ServletHolder(new DumpServlet()),"/dump/*");

        server.start();
        server.join();
    }
}

Embedding Web Applications

A WebAppContext is an extension of a ServletContextHandler that uses the standard layout and web.xml to configure the servlets, filters and other features from a web.xml and/or annotations. The following OneWebApp example configures the Jetty test webapp. Web applications can use resources the container provides, and in this case a LoginService is needed and also configured:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
//
//  ========================================================================
//  Copyright (c) 1995-2014 Mort Bay Consulting Pty. Ltd.
//  ------------------------------------------------------------------------
//  All rights reserved. This program and the accompanying materials
//  are made available under the terms of the Eclipse Public License v1.0
//  and Apache License v2.0 which accompanies this distribution.
//
//      The Eclipse Public License is available at
//
//      The Apache License v2.0 is available at
//
//  You may elect to redistribute this code under either of these licenses.
//  ========================================================================
//

package org.eclipse.jetty.embedded;

import java.lang.management.ManagementFactory;

import org.eclipse.jetty.jmx.MBeanContainer;
import org.eclipse.jetty.security.HashLoginService;
import org.eclipse.jetty.server.Server;
import org.eclipse.jetty.webapp.WebAppContext;

public class OneWebApp
{
    public static void main(String[] args) throws Exception
    {
        // Create a basic jetty server object that will listen on port 8080. Note that if you set this to port 0 then
        // a randomly available port will be assigned that you can either look in the logs for the port,
        // or programmatically obtain it for use in test cases.
        Server server = new Server(8080);

        // Setup JMX
        MBeanContainer mbContainer=new MBeanContainer(ManagementFactory.getPlatformMBeanServer());
        server.addBean(mbContainer);

        // The WebAppContext is the entity that controls the environment in which a web application lives and
        // breathes. In this example the context path is being set to "/" so it is suitable for serving root context
        // requests and then we see it setting the location of the war. A whole host of other configurations are
        // available, ranging from configuring to support annotation scanning in the webapp (through
        // PlusConfiguration) to choosing where the webapp will unpack itself.
        WebAppContext webapp = new WebAppContext();
        webapp.setContextPath("/");
        webapp.setWar("../../jetty-distribution/target/distribution/demo-base/webapps/test.war");

        // A WebAppContext is a ContextHandler as well so it needs to be set to the server so it is aware of where to
        // send the appropriate requests.
        server.setHandler(webapp);

        // Configure a LoginService
        // Since this example is for our test webapp, we need to setup a LoginService so this shows how to create a
        // very simple hashmap based one. The name of the LoginService needs to correspond to what is configured in
        // the webapp's web.xml and since it has a lifecycle of its own we register it as a bean with the Jetty
        // server object so it can be started and stopped according to the lifecycle of the server itself.
        HashLoginService loginService = new HashLoginService();
        loginService.setName("Test Realm");
        loginService.setConfig("src/test/resources/realm.properties");
        server.addBean(loginService);

        // Start things up! By using the server.join() the server thread will join with the current thread.
        // See "http://docs.oracle.com/javase/1.5.0/docs/api/java/lang/Thread.html#join()" for more details.
        server.start();
        server.join();
    }
}

Like Jetty XML

The typical way to configure an instance of the Jetty server is via jetty.xml and associated configuration files. However the Jetty XML configuration format is just a simple rendering of what you can do in code; it is very simple to write embedded code that does precisely what the jetty.xml configuration does. The LikeJettyXml example following renders in code the behaviour obtained from the configuration files:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
//
//  ========================================================================
//  Copyright (c) 1995-2014 Mort Bay Consulting Pty. Ltd.
//  ------------------------------------------------------------------------
//  All rights reserved. This program and the accompanying materials
//  are made available under the terms of the Eclipse Public License v1.0
//  and Apache License v2.0 which accompanies this distribution.
//
//      The Eclipse Public License is available at
//
//      The Apache License v2.0 is available at
//
//  You may elect to redistribute this code under either of these licenses.
//  ========================================================================
//

package org.eclipse.jetty.embedded;

import java.lang.management.ManagementFactory;

import org.eclipse.jetty.deploy.DeploymentManager;
import org.eclipse.jetty.deploy.PropertiesConfigurationManager;
import org.eclipse.jetty.deploy.providers.WebAppProvider;
import org.eclipse.jetty.jmx.MBeanContainer;
import org.eclipse.jetty.security.HashLoginService;
import org.eclipse.jetty.server.Handler;
import org.eclipse.jetty.server.HttpConfiguration;
import org.eclipse.jetty.server.HttpConnectionFactory;
import org.eclipse.jetty.server.LowResourceMonitor;
import org.eclipse.jetty.server.NCSARequestLog;
import org.eclipse.jetty.server.SecureRequestCustomizer;
import org.eclipse.jetty.server.Server;
import org.eclipse.jetty.server.ServerConnector;
import org.eclipse.jetty.server.SslConnectionFactory;
import org.eclipse.jetty.server.handler.ContextHandlerCollection;
import org.eclipse.jetty.server.handler.DefaultHandler;
import org.eclipse.jetty.server.handler.HandlerCollection;
import org.eclipse.jetty.server.handler.RequestLogHandler;
import org.eclipse.jetty.server.handler.StatisticsHandler;
import org.eclipse.jetty.util.ssl.SslContextFactory;
import org.eclipse.jetty.util.thread.QueuedThreadPool;
import org.eclipse.jetty.util.thread.ScheduledExecutorScheduler;

public class LikeJettyXml
{
    public static void main(String[] args) throws Exception
    {
        String jetty_home = System.getProperty("jetty.home","../../jetty-distribution/target/distribution");
        String jetty_base = System.getProperty("jetty.home","../../jetty-distribution/target/distribution/demo-base");
        System.setProperty("jetty.home",jetty_home);
        System.setProperty("jetty.base",jetty_base);


        // === jetty.xml ===
        // Setup Threadpool
        QueuedThreadPool threadPool = new QueuedThreadPool();
        threadPool.setMaxThreads(500);

        // Server
        Server server = new Server(threadPool);

        // Scheduler
        server.addBean(new ScheduledExecutorScheduler());

        // HTTP Configuration
        HttpConfiguration http_config = new HttpConfiguration();
        http_config.setSecureScheme("https");
        http_config.setSecurePort(8443);
        http_config.setOutputBufferSize(32768);
        http_config.setRequestHeaderSize(8192);
        http_config.setResponseHeaderSize(8192);
        http_config.setSendServerVersion(true);
        http_config.setSendDateHeader(false);
        // httpConfig.addCustomizer(new ForwardedRequestCustomizer());

        // Handler Structure
        HandlerCollection handlers = new HandlerCollection();
        ContextHandlerCollection contexts = new ContextHandlerCollection();
        handlers.setHandlers(new Handler[] { contexts, new DefaultHandler() });
        server.setHandler(handlers);

        // Extra options
        server.setDumpAfterStart(false);
        server.setDumpBeforeStop(false);
        server.setStopAtShutdown(true);


        // === jetty-jmx.xml ===
        MBeanContainer mbContainer=new MBeanContainer(ManagementFactory.getPlatformMBeanServer());
        server.addBean(mbContainer);


        // === jetty-http.xml ===
        ServerConnector http = new ServerConnector(server,new HttpConnectionFactory(http_config));
        http.setPort(8080);
        http.setIdleTimeout(30000);
        server.addConnector(http);


        // === jetty-https.xml ===
        // SSL Context Factory
        SslContextFactory sslContextFactory = new SslContextFactory();
        sslContextFactory.setKeyStorePath(jetty_home + "/etc/keystore");
        sslContextFactory.setKeyStorePassword("OBF:1vny1zlo1x8e1vnw1vn61x8g1zlu1vn4");
        sslContextFactory.setKeyManagerPassword("OBF:1u2u1wml1z7s1z7a1wnl1u2g");
        sslContextFactory.setTrustStorePath(jetty_home + "/etc/keystore");
        sslContextFactory.setTrustStorePassword("OBF:1vny1zlo1x8e1vnw1vn61x8g1zlu1vn4");
        sslContextFactory.setExcludeCipherSuites(
                "SSL_RSA_WITH_DES_CBC_SHA",
                "SSL_DHE_RSA_WITH_DES_CBC_SHA",
                "SSL_DHE_DSS_WITH_DES_CBC_SHA",
                "SSL_RSA_EXPORT_WITH_RC4_40_MD5",
                "SSL_RSA_EXPORT_WITH_DES40_CBC_SHA",
                "SSL_DHE_RSA_EXPORT_WITH_DES40_CBC_SHA",
                "SSL_DHE_DSS_EXPORT_WITH_DES40_CBC_SHA");

        // SSL HTTP Configuration
        HttpConfiguration https_config = new HttpConfiguration(http_config);
        https_config.addCustomizer(new SecureRequestCustomizer());

        // SSL Connector
        ServerConnector sslConnector = new ServerConnector(server,
            new SslConnectionFactory(sslContextFactory,"http/1.1"),
            new HttpConnectionFactory(https_config));
        sslConnector.setPort(8443);
        server.addConnector(sslConnector);


        // === jetty-deploy.xml ===
        DeploymentManager deployer = new DeploymentManager();
        deployer.setContexts(contexts);
        deployer.setContextAttribute("org.eclipse.jetty.server.webapp.ContainerIncludeJarPattern",".*/servlet-api-[^/]*\\.jar$");

        WebAppProvider webapp_provider = new WebAppProvider();
        webapp_provider.setMonitoredDirName(jetty_base + "/webapps");
        webapp_provider.setDefaultsDescriptor(jetty_home + "/etc/webdefault.xml");
        webapp_provider.setScanInterval(1);
        webapp_provider.setExtractWars(true);
        webapp_provider.setConfigurationManager(new PropertiesConfigurationManager());

        deployer.addAppProvider(webapp_provider);
        server.addBean(deployer);


        // === jetty-stats.xml ===
        StatisticsHandler stats = new StatisticsHandler();
        stats.setHandler(server.getHandler());
        server.setHandler(stats);


        // === jetty-requestlog.xml ===
        NCSARequestLog requestLog = new NCSARequestLog();
        requestLog.setFilename(jetty_home + "/logs/yyyy_mm_dd.request.log");
        requestLog.setFilenameDateFormat("yyyy_MM_dd");
        requestLog.setRetainDays(90);
        requestLog.setAppend(true);
        requestLog.setExtended(true);
        requestLog.setLogCookies(false);
        requestLog.setLogTimeZone("GMT");
        RequestLogHandler requestLogHandler = new RequestLogHandler();
        requestLogHandler.setRequestLog(requestLog);
        handlers.addHandler(requestLogHandler);


        // === jetty-lowresources.xml ===
        LowResourceMonitor lowResourcesMonitor=new LowResourceMonitor(server);
        lowResourcesMonitor.setPeriod(1000);
        lowResourcesMonitor.setLowResourcesIdleTimeout(200);
        lowResourcesMonitor.setMonitorThreads(true);
        lowResourcesMonitor.setMaxConnections(0);
        lowResourcesMonitor.setMaxMemory(0);
        lowResourcesMonitor.setMaxLowResourcesTime(5000);
        server.addBean(lowResourcesMonitor);


        // === test-realm.xml ===
        HashLoginService login = new HashLoginService();
        login.setName("Test Realm");
        login.setConfig(jetty_base + "/etc/realm.properties");
        login.setRefreshInterval(0);
        server.addBean(login);


        // Start the server
        server.start();
        server.join();
    }
}
Previous  Top  Next
Chapter 26. Embedding  Home  Embedded Examples
See an error or something missing? Contribute to this documentation at  Github!(Generated: 2014-07-29T01:00:29-07:00)

jetty tutorial的更多相关文章

  1. Jetty 嵌入式开发（实例）

    我尝试了jetty几个版本,类的使用有些差异,在此记录下jettyVersion = 9.0.2.v20130417 的部分实例 maven 依赖及配置: <properties> < ...

  2. Jetty 嵌入式启动官方完整教程

    网上太多了,不如直接看官方的这个全面. http://wiki.eclipse.org/Jetty/Tutorial/Embedding_Jetty 入门地址: http://wiki.eclipse ...

  3. Message高级特性 & 内嵌Jetty实现文件服务器

    1. Messaage Properties  常见属性 更多的属性以及介绍参考:http://activemq.apache.org/activemq-message-properties.html ...

  4. jetty+mongodb 配置session外部数据库存储

    monbgodb简介 主页 http://www.mongodb.org/ oschina.net 介绍页 http://www.oschina.net/p/mongodb MongoDB是一个介于关 ...

  5. apache+jetty 配置web jsp服务器负载均衡

    首先,查找中文资料,貌似很少,有一个网友写了点,但是1版本过老,2有些地方有错误. 经过我自己摸索,记录一下.这个图很简洁明了 第一阶段 ,配置jetty 首先从 http://download.ec ...

  6. 使用ActiveMQ 传输文件 以及使用Jetty搭建内嵌文件服务器

    使用Active发送文件 ActiveMq 本身提供对于传输文件的支持. 1. 直接传输文件: 使用connection.createOutputStream 的形式.这种方式适合小文件.不能传输大文 ...

  7. [置顶] Embedded Server：像写main函数一样写Web Server

    1.传统的JEE Web Server 传统的JEE中,如果我们想要部署一个Web Application,我们需要首先安装一个Container Server,如JBoss,WebLogic,Tom ...

  8. spring 3 mvc hello world + mavern +jetty

    Spring 3 MVC hello world example By mkyong | August 2, 2011 | Updated : June 15, 2015 In this tutori ...

  9. JXSE and Equinox Tutorial, Part 2

    http://java.dzone.com/articles/jxse-and-equinox-tutorial-part-0 ———————————————————————————————————— ...

随机推荐

  1. Mysql基本操作(远程登陆，启动，停止，重启，授权)

    1.查看mysql版本 方法一:status; 方法二:select version(); 2.Mysql启动.停止.重启常用命令 a.启动方式 1.使用 service 启动: [root@loca ...

  2. Spring map注入

    类test.Configurations定义如下 @Getter @Setter public class Configurations { private Map<AnswerSourceTy ...

  3. .NET/C# 在代码中测量代码执行耗时的建议（比较系统性能计数器和系统时间）

    我们有很多种方法评估一个方法的执行耗时,比如使用性能分析工具,使用基准性能测试.不过传统的在代码中编写计时的方式依然有效,因为它可以生产环境或用户端得到真实环境下的执行耗时. 如果你希望在 .NET/ ...

  4. .NET/C# 使用反射调用含 ref 或 out 参数的方法

    使用反射,我们可以很容易地在运行时调用一些编译时无法确定的属性.方法等.然而,如果方法的参数中包含 ref 或 out 关键字的时候,又该怎么调用呢? 本文将介绍如何反射调用含 ref 或 out 关 ...

  5. chrom调试javascript

    上面的文章已经大致介绍了一下console对象具体有哪些方面以及基本的应用,下面简单介绍一下如何利用好chrome控制台这个神器好好调试javascript代码(这个才是我们真正能用到实处的地方) 1 ...

  6. 浅谈iOS学习之路（转）

    转眼学习iOS已经快两年的时间了,这个路上有挫折也有喜悦,一步步走过来发现这个过程是我这一辈子的财富,我以前的老大总是对我说,年轻就是最大的资本(本人91年),现在才算是慢慢的体会到,反观自己走过的这 ...

  7. CCFlow SDK模式开发（有比较详细的代码，以服务的形式与ccflow数据库进行数据交互）

    http://www.cnblogs.com/s0611163/p/3963142.html 需求: 1.业务数据要保存在我们自己的数据库里     2.CCFlow有保存草稿的功能,但是领导要求每个 ...

  8. winform 勾选可以改变框控件

    public partial class UCCheck : UserControl { [Browsable(true), Category("修改属性"), Descripti ...

  9. Spring MVC @ResponseBody和@RequestBody使用

    @ResponseBody用法: 作用:该注解用于将Controller的方法返回的对象,根据HTTP Request Header的Accept的内容,通过适当的HttpMessageConvert ...

  10. Bootstrap-CL：多媒体对象

    ylbtech-Bootstrap-CL:多媒体对象 1.返回顶部 1. Bootstrap 多媒体对象(Media Object) 本章我们将讲解 Bootstrap 中的多媒体对象(Media O ...
