一. Activiti相关概念

1. Activiti介绍

    Activiti是基于Apache许可的开源BPM平台，创始人Tom Baeyens原是JBPM架构师，可以理解为与JBPM出自同一祖师爷。它提供了Eclipse插件，开发可以通过插件直接绘制业务流程图。基于Spring，ibatis等框架，并在此之上构建了非常清晰的开发框架。是由Alfresco软件发布的业务流程管理（BPM）框架，它是覆盖了业务流程管理、工作流、服务协作等领域的一个开源的、灵活的、易扩展的可执行流程语言框架。 本文基于Activiti7的Activiti Core，基于Spring Boot做简单学习总结。（Activiti最新版本向微服务这边靠齐了，并分Activiti Core与Activiti Cloud两块，Activiti Cloud还没研究）

2. 核心类

2.1 ProcessEngine

    流程引擎的抽象，可以通过此类获取需要的所有服务。

2.2 服务(Service)类

    通过ProcessEngine获取，Activiti将不同生命周期的服务封装在不同Service中，包括定义、部署、运行。通过服务类可获取相关生命周期中的服务信息。

2.2.1 TaskService

    流程运行过程中，每个任务节点的相关操作接口，如complete,delete,delegate等。

2.2.2 RepositoryService

    流程定义和部署相关的存储服务。

2.2.3 RuntimeService

    流程运行时相关的服务，如根据流程好启动流程实例startProcessInstanceByKey。

2.2.3 HistoryService

    历史记录相关服务接口。

2.3 CommandContextIntercepter或CommandExecutor

    Activiti使用命令模式作为基础开发模式，如Service中调用的各个方法都对应相应的命令对象。Service将请求委托给命令对象，命令对象来命令接受者，接受者接收后执行并返回结果。而CommandContextIntercepter的作用是拦截所有命令，并在命令前后执行一些公共方法。

2.4 核心业务对象

    org.activiti.engine.impl.persistence.entity包下的类，包括Task，ProcessInstance，Execution等。会根据不同职责实现相应接口的方法(如需要持久化则继承PersistentObject接口)，与传统的实体类不同。

3. 上下文组件(Context)

    用来保存生命周期比较长，全局性的信息，类似Application，主要包括如下三类。

3.1 CommandContext

    命令上下文，保存每个命令必要的资源，如持久化需要的session。

3.2 ProcessEngineConfigurationImpl

    流程引擎相关配置信息，整个引擎全局的配置信息，如数据源DataSource等。该对象为单例，在流程引擎创建的时候初始化。

3.3 ExecutionContext

    持有ExecutionEntity对象。

4. 持久化组件

    Activiti使用ibatis作OR映射，并在此基础上增加设计了自己的持久化框架。在流程引擎创建时初始化。顶层接口Session、SessionFactory。Session有两个实现类：DbSqlSession，负责sql表达式的执行。AbstractManager负责对象的持久化操作。SessionFactory有两个实现类：DbSqlSessionFactory负责DbSqlSession相关操作，GenericManagerFactory负责AbstractManager相关操作。

5. Event-Listener组件

    Activiti允许客户代码介入流程执行，提供了事件监听组件。监听的事件类型可以分为TaskListener、JavaDelegate、Expression、ExecutionListener。ProcessEngineConfigurationImpl持有DelegateInterceptor的某个实例，方便调用handleInvocation。

6. Cache组件

    DbSqlSession中有cache的实现，Activiti基于List和Map来做缓存。如查询时先查缓存，没有则直接查询并放入缓存。

7. 异步执行组件

    Activiti可以执行任务，JobExecutor为启核心类，JobExecutor包含三个主要属性：JobAcquisitionThread，BlockingQueue，ThreadPoolExecutor。方法ProcessEngines在引擎启动时调用JobExecutor.start，JobAcquisitionThread 线程即开始工作，其run方法不断循环执行AcquiredJobs中的job，执行一次后线程等待一定时间直到超时或者JobExecutor.jobWasAdded方法，因为有新任务而被调用。

8. PVM:Process Virtal Machine

    流程虚拟机API暴露了流程虚拟机的POJO核心，流程虚拟机API描述了一个工作流流程必备的组件，这些组件包括：

    PvmProcessDefinition：流程的定义，形象点说就是用户画的那个图。静态含义。

    PvmProcessInstance：流程实例，用户发起的某个PvmProcessDefinition的一个实例，动态含义。

    PvmActivity：流程中的一个节点

    PvmTransition：衔接各个节点之间的路径，形象点说就是图中各个节点之间的连接线。

    PvmEvent：流程执行过程中触发的事件

二. Eclipse插件安装：

    我的Eclipse版本如下：



    下载离线安装包（在线安装始终失败，应该出于网络限制），地址：http://www.activiti.org/designer/archived/activiti-designer-5.18.0.zip

    离线安装包安装安装依然提示相关包找不到，于是下载另外三个依赖包（org.eclipse.emf.transaction_1.4.0.v20100331-1738.jar、org.eclipse.emf.validation_1.7.0.201306111341.jar、org.eclipse.emf.workspace_1.5.1.v20120328-0001.jar，在Maven仓库可以找到），放到Eclipse的plugin目录下，继续安装，如下：



    确定后勾选相关选项，完成安装，重启Eclipse，New->Other



    出现以上标志，则安装完成。

三. 项目搭建

1. 新建Spring Boot工程

    （我的Eclipse已经安装Spring Boot插件）



    然后Next->Next…->Finish即可，然后改application.properties为application.yml（个人习惯）

2. 引入Activiti相关依赖

    在pom属性中定义版本号，并添加Activiti相关依赖：

<activiti-dependencies.version>7.0.56</activiti-dependencies.version>

<dependencyManagement>
  <dependencies>
    <dependency>
      <groupId>org.activiti.dependencies</groupId>
      <artifactId>activiti-dependencies</artifactId>
      <version>${activiti-dependencies.version}</version>
      <scope>import</scope>
      <type>pom</type>
    </dependency>
  </dependencies>
</dependencyManagement>

<dependency>
      <groupId>org.activiti</groupId>
      <artifactId>activiti-spring-boot-starter</artifactId>
</dependency>

    由于Activiti默认使用H2数据库，所以需添加H2数据库支持（这里使用此SpringBoot版本默认1.4.197）：

<dependency>
      <groupId>com.h2database</groupId>
      <artifactId>h2</artifactId>
</dependency>

    出现错误：Missing artifact org.activiti:activiti-spring-boot-starter:jar:7.0.56

    添加私服仓库地址：

<repositories>
        <repository>
          <id>alfresco</id>
          <name>Activiti Releases</name>
          <url>https://artifacts.alfresco.com/nexus/content/repositories/activiti-releases/</url>
          <releases>
            <enabled>true</enabled>
          </releases>
        </repository>
</repositories>

    错误消失。

3. 创建流程图

    在此版本Activiti+SpringBoot，默认加载/processes/目录下流程，于是在resources下新建processes目录，并在目录下new->Other，如下：



    使用Activiti图编辑工具打开，创建如下流程（创建过程在此不介绍，就是右侧工具栏的运用）：

4. 启动工程

    看日志：



    从日志中可以看出，流程引擎已经默认创建，并可以看到使用的默认数据源是H2的数据源，我们创建的流程也已经部署。

5. 修改配置

    在正常使用中，一般系统会有自己的数据库，而不会采用默认内存的H2数据库，这里以MySQL为例。修改application.yml。

5.1 添加MySQL依赖

<!--使用mysql数据库,导入mysql驱动-->
<dependency>
  <groupId>mysql</groupId>
  <artifactId>mysql-connector-java</artifactId>
</dependency>

5.2 修改数据库

spring:
  ##数据库连接信息
  datasource:
    # 数据源配置
    url: jdbc:mysql://127.0.0.1:3306/activity?useUnicode=true&characterEncoding=utf-8&useSSL=false
    username: root
    password: root
    driver-class-name: com.mysql.jdbc.Driver
    # SQLException: XAER_INVAL: Invalid arguments (or unsupported command)问题
    xa:
      properties:
        pinGlobalTxToPhysicalConnection: true
        useServerPrepStmts: true

5.3 Activiti相关配置

  # 参考配置https://www.cnblogs.com/liaojie970/p/8857710.html
  activiti:
    # 自动建表
    database-schema: ACTIVITI
    database-schema-update: true
    history-level: full
    db-history-used: true

    注意：

    database-schema-update表示启动时检查数据库表，不存在则创建

    history-level表示哪种情况下使用历史表，这里配置为full表示全部记录历史，方便绘制流程图

    db-history-used为true表示使用历史表，如果不配置，则工程启动后可以检查数据库，只建立了17张表，历史表没有建立，则流程图及运行节点无法展示（暂未找到可行方式）

5.4 附上application.yml完整配置：

# 服务配置
server:
  display-name: actdemo
  port: 8085

# Spring相关配置

spring:

##数据库连接信息

  datasource:

# 数据源配置

    url: jdbc:mysql://127.0.0.1:3306/activity?useUnicode=true&characterEncoding=utf-8&useSSL=false

    username: root

    password: 888

    driver-class-name: com.mysql.jdbc.Driver
<span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"># SQLException: XAER_INVAL: Invalid arguments (or unsupported command)问题</span></span></span></span>

xa:

      properties:

        pinGlobalTxToPhysicalConnection: true

        useServerPrepStmts: true
thymeleaf:

    mode: HTML

    encoding: utf-8

# 禁用缓存

    cache: false

  application:

# 注册应用名

    name: actdemo

  mvc:

# 静态资源路径

    static-path-pattern: /static/**

# 参考配置https://www.cnblogs.com/liaojie970/p/8857710.html

  activiti:

# 自动建表

    database-schema: ACTIVITI

    database-schema-update: true

    history-level: full

    db-history-used: true

5.5 启动工程

    观察日志，流程引擎已成功加载，并已使用MySQL数据库，如下：



    再看数据库，已经创建25张表（老版本的Activiti创建表有手动执行SQL和通过调用流程引擎创建两种方式，该版本与SpringBoot整合后，启动默认创建需要的表）：



    注意：

    原SpringBoot工程使用版本2.1.1.RELEASE，启动始终失败，各种错误，后改为2.0.4.RELEASE版本，则启动正常。

6. 编写实例

    本例子使用Thymeleaf做前端页面展示（SpringBoot推荐使用），并创建控制器Controller调用工作流接口与前端交互。

6.1 引入Thymeleaf依赖，（前端使用Thymeleaf的配置已经在application.yml中）

<!-- Thymeleaf依赖 -->
<dependency>
  <groupId>org.springframework.boot</groupId>
  <artifactId>spring-boot-starter-thymeleaf</artifactId>
</dependency>

6.2 创建Controller控制器

    创建启动流程方法，主要代码如下

/**
     * <p>启动请假流程</p>
     * @return String 流程实例ID
     * @author FRH
     * @time 2018年12月10日上午11:03:36
     * @version 1.0
     */
    @RequestMapping(value="/start")
    @ResponseBody
    public String start() {
        // xml中定义的ID
        String instanceKey = "leaveProcess";
        logger.info("开启请假流程...");
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 设置流程参数，开启流程</span></span></span></span>
    <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">Map</span></span></span></span>&lt;<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">String</span></span></span></span>,<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">Object</span></span></span></span>&gt; map = <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">new</span></span></span></span> HashMap&lt;<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">String</span></span></span></span>,<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">Object</span></span></span></span>&gt;();
    map.put(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"jobNumber"</span></span></span></span>,<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"A1001"</span></span></span></span>);
    map.put(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"busData"</span></span></span></span>,<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"bus data"</span></span></span></span>);
    ProcessInstance instance = runtimeService.startProcessInstanceByKey(instanceKey, map);<span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">//使用流程定义的key启动流程实例，key对应helloworld.bpmn文件中id的属性值，使用key值启动，默认是按照最新版本的流程定义启动</span></span></span></span>

    logger.info(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"启动流程实例成功:{}"</span></span></span></span>, instance);
    logger.info(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"流程实例ID:{}"</span></span></span></span>, instance.getId());
    logger.info(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"流程定义ID:{}"</span></span></span></span>, instance.getProcessDefinitionId());

    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">//验证是否启动成功</span></span></span></span>
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">//通过查询正在运行的流程实例来判断</span></span></span></span>
    ProcessInstanceQuery processInstanceQuery = runtimeService.createProcessInstanceQuery();
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">//根据流程实例ID来查询</span></span></span></span>
    <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">List</span></span></span></span>&lt;ProcessInstance&gt; runningList = processInstanceQuery.processInstanceId(instance.getProcessInstanceId()).list();
    logger.info(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"根据流程ID查询条数:{}"</span></span></span></span>, runningList.size());

    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 返回流程ID</span></span></span></span>
    <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">return</span></span></span></span> instance.getId();
}

6.3 流程跟踪与流程图展示

    Activiti流程图展示，使用流程图生成器，本例生成的流程图在页面使用如下方式展示即可：

<embed src="/demo/showImg?instanceId=5070fd58-f859-11e8-a359-484d7ec5762d" style="display:block;width:1000px;height:450px" />

    引入相关工具包，版本使用默认版本7.0.65

<!-- Activiti生成流程图 -->
<dependency>
  <groupId>org.activiti</groupId>
  <artifactId>activiti-image-generator</artifactId>
</dependency>

    调用输出流程图

/**
     * <p>查看当前流程图</p>
     * @param instanceId 流程实例
     * @param response void 响应
     * @author FRH
     * @time 2018年12月10日上午11:14:12
     * @version 1.0
     */
    @ResponseBody
    @RequestMapping(value="/showImg")
    public void showImg(String instanceId, HttpServletResponse response) {
        /*
         * 参数校验
         */
        logger.info("查看完整流程图！流程实例ID:{}", instanceId);
        if(StringUtils.isBlank(instanceId)) return;
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     *  获取流程实例
     */</span></span></span></span>
    HistoricProcessInstance processInstance = historyService.createHistoricProcessInstanceQuery().processInstanceId(instanceId).singleResult();
    <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">if</span></span></span></span>(processInstance == <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">null</span></span></span></span>) {
        logger.error(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"流程实例ID:{}没查询到流程实例！"</span></span></span></span>, instanceId);
        <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">return</span></span></span></span>;
    }

    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 根据流程对象获取流程对象模型</span></span></span></span>
    BpmnModel bpmnModel = repositoryService.getBpmnModel(processInstance.getProcessDefinitionId());

    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     *  查看已执行的节点集合
     *  获取流程历史中已执行节点，并按照节点在流程中执行先后顺序排序
     */</span></span></span></span>
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 构造历史流程查询</span></span></span></span>
    HistoricActivityInstanceQuery historyInstanceQuery = historyService.createHistoricActivityInstanceQuery().processInstanceId(instanceId);
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 查询历史节点</span></span></span></span>
    List&lt;HistoricActivityInstance&gt; historicActivityInstanceList = historyInstanceQuery.orderByHistoricActivityInstanceStartTime().asc().list();
    <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">if</span></span></span></span>(historicActivityInstanceList == <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">null</span></span></span></span> || historicActivityInstanceList.size() == <span class="hljs-number"><span class="hljs-number"><span class="hljs-number"><span class="hljs-number">0</span></span></span></span>) {
        logger.info(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"流程实例ID:{}没有历史节点信息！"</span></span></span></span>, instanceId);
        outputImg(response, bpmnModel, <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">null</span></span></span></span>, <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">null</span></span></span></span>);
        <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">return</span></span></span></span>;
    }
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 已执行的节点ID集合(将historicActivityInstanceList中元素的activityId字段取出封装到executedActivityIdList)</span></span></span></span>
    List&lt;String&gt; executedActivityIdList = historicActivityInstanceList.stream().map(item -&gt; item.getActivityId()).collect(Collectors.toList());

    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     *  获取流程走过的线
     */</span></span></span></span>
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 获取流程定义</span></span></span></span>
    ProcessDefinitionEntity processDefinition = (ProcessDefinitionEntity) ((RepositoryServiceImpl) repositoryService).getDeployedProcessDefinition(processInstance.getProcessDefinitionId());
    List&lt;String&gt; flowIds = ActivitiUtils.getHighLightedFlows(bpmnModel, processDefinition, historicActivityInstanceList);

    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     * 输出图像，并设置高亮
     */</span></span></span></span>
    outputImg(response, bpmnModel, flowIds, executedActivityIdList);
}

<span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/**
 * &lt;p&gt;输出图像&lt;/p&gt;
 * </span></span></span><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag">@param</span></span></span></span></span></span></span><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"> response 响应实体
 * </span></span></span><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag">@param</span></span></span></span></span></span></span><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"> bpmnModel 图像对象
 * </span></span></span><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag">@param</span></span></span></span></span></span></span><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"> flowIds 已执行的线集合
 * </span></span></span><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag">@param</span></span></span></span></span></span></span><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"> executedActivityIdList void 已执行的节点ID集合
 * </span></span></span><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag">@author</span></span></span></span></span></span></span><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"> FRH
 * </span></span></span><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag">@time</span></span></span></span></span></span></span><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"> 2018年12月10日上午11:23:01
 * </span></span></span><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag">@version</span></span></span></span></span></span></span><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"> 1.0
 */</span></span></span></span>
<span class="hljs-function"><span class="hljs-keyword"><span class="hljs-function"><span class="hljs-keyword"><span class="hljs-function"><span class="hljs-keyword"><span class="hljs-function"><span class="hljs-keyword">private</span></span></span></span></span></span></span><span class="hljs-function"><span class="hljs-function"><span class="hljs-function"> </span></span></span><span class="hljs-keyword"><span class="hljs-function"><span class="hljs-keyword"><span class="hljs-function"><span class="hljs-keyword"><span class="hljs-function"><span class="hljs-keyword">void</span></span></span></span></span></span></span><span class="hljs-function"><span class="hljs-function"><span class="hljs-function"> </span></span></span><span class="hljs-title"><span class="hljs-function"><span class="hljs-title"><span class="hljs-function"><span class="hljs-title"><span class="hljs-function"><span class="hljs-title">outputImg</span></span></span></span></span></span></span><span class="hljs-params"><span class="hljs-function"><span class="hljs-params"><span class="hljs-function"><span class="hljs-params"><span class="hljs-function"><span class="hljs-params">(HttpServletResponse response, BpmnModel bpmnModel, List&lt;String&gt; flowIds, List&lt;String&gt; executedActivityIdList)</span></span></span></span></span></span></span><span class="hljs-function"><span class="hljs-function"><span class="hljs-function"> </span></span></span></span>{
    InputStream imageStream = <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">null</span></span></span></span>;
    <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">try</span></span></span></span> {
        imageStream = processDiagramGenerator.generateDiagram(bpmnModel, executedActivityIdList, flowIds, <span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"宋体"</span></span></span></span>, <span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"微软雅黑"</span></span></span></span>, <span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"黑体"</span></span></span></span>, <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">true</span></span></span></span>, <span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"png"</span></span></span></span>);
        <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 输出资源内容到相应对象</span></span></span></span>
        <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">byte</span></span></span></span>[] b = <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">new</span></span></span></span> <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">byte</span></span></span></span>[<span class="hljs-number"><span class="hljs-number"><span class="hljs-number"><span class="hljs-number">1024</span></span></span></span>];
        <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">int</span></span></span></span> len;
        <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">while</span></span></span></span> ((len = imageStream.read(b, <span class="hljs-number"><span class="hljs-number"><span class="hljs-number"><span class="hljs-number">0</span></span></span></span>, <span class="hljs-number"><span class="hljs-number"><span class="hljs-number"><span class="hljs-number">1024</span></span></span></span>)) != -<span class="hljs-number"><span class="hljs-number"><span class="hljs-number"><span class="hljs-number">1</span></span></span></span>) {
            response.getOutputStream().write(b, <span class="hljs-number"><span class="hljs-number"><span class="hljs-number"><span class="hljs-number">0</span></span></span></span>, len);
        }
        response.getOutputStream().flush();
    }<span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">catch</span></span></span></span>(Exception e) {
        logger.error(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"流程图输出异常！"</span></span></span></span>, e);
    } <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">finally</span></span></span></span> { <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 流关闭</span></span></span></span>
        StreamUtils.closeInputStream(imageStream);
    }
}

    流程图工具类ActivitiUtils

package com.mypro.activiti.utils;

import java.util.ArrayList;

import java.util.List;

import org.activiti.bpmn.model.BpmnModel;

import org.activiti.bpmn.model.FlowNode;

import org.activiti.bpmn.model.SequenceFlow;

import org.activiti.engine.history.HistoricActivityInstance;

import org.activiti.engine.impl.persistence.entity.ProcessDefinitionEntity;

/**
<p>Activiti工作流工具类</p>
@author FRH
@time 2018年12月10日上午11:26:02
@version 1.0

*/

public class ActivitiUtils {

/**
<p>获取流程走过的线</p>
@param bpmnModel 流程对象模型
@param processDefinitionEntity 流程定义对象
@param historicActivityInstances 历史流程已经执行的节点，并已经按执行的先后顺序排序
@return List<String> 流程走过的线
@author FRH
@time 2018年12月10日上午11:26:19
@version 1.0

*/

public static List<String> getHighLightedFlows(BpmnModel bpmnModel, ProcessDefinitionEntity processDefinitionEntity, List<HistoricActivityInstance> historicActivityInstances) {

// 用以保存高亮的线flowId

List<String> highFlows = new ArrayList<String>();

if(historicActivityInstances == null || historicActivityInstances.size() == 0) return highFlows;

// 遍历历史节点

for (int i = 0; i < historicActivityInstances.size() - 1; i++) {

// 取出已执行的节点

HistoricActivityInstance activityImpl_ = historicActivityInstances.get(i);
 <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 用以保存后续开始时间相同的节点</span></span></span></span>
 List&lt;FlowNode&gt; sameStartTimeNodes = <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">new</span></span></span></span> ArrayList&lt;FlowNode&gt;();

 <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 获取下一个节点（用于连线）</span></span></span></span>
 FlowNode sameActivityImpl = getNextFlowNode(bpmnModel, historicActivityInstances, i, activityImpl_);

//          FlowNode sameActivityImpl = (FlowNode) bpmnModel.getMainProcess().getFlowElement(historicActivityInstances.get(i + 1).getActivityId());
        <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 将后面第一个节点放在时间相同节点的集合里</span></span></span></span>
        <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">if</span></span></span></span>(sameActivityImpl != <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">null</span></span></span></span>) sameStartTimeNodes.add(sameActivityImpl);

        <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 循环后面节点，看是否有与此后继节点开始时间相同的节点，有则添加到后继节点集合</span></span></span></span>
        <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">for</span></span></span></span> (<span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">int</span></span></span></span> j = i + <span class="hljs-number"><span class="hljs-number"><span class="hljs-number"><span class="hljs-number">1</span></span></span></span>; j &lt; historicActivityInstances.size() - <span class="hljs-number"><span class="hljs-number"><span class="hljs-number"><span class="hljs-number">1</span></span></span></span>; j++) {
            HistoricActivityInstance activityImpl1 = historicActivityInstances.get(j);<span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 后续第一个节点</span></span></span></span>
            HistoricActivityInstance activityImpl2 = historicActivityInstances.get(j + <span class="hljs-number"><span class="hljs-number"><span class="hljs-number"><span class="hljs-number">1</span></span></span></span>);<span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 后续第二个节点</span></span></span></span>
            <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">if</span></span></span></span> (activityImpl1.getStartTime().getTime() != activityImpl2.getStartTime().getTime()) <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">break</span></span></span></span>;

            <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 如果第一个节点和第二个节点开始时间相同保存</span></span></span></span>
            FlowNode sameActivityImpl2 = (FlowNode) bpmnModel.getMainProcess().getFlowElement(activityImpl2.getActivityId());
            sameStartTimeNodes.add(sameActivityImpl2);
        }

        <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 得到节点定义的详细信息</span></span></span></span>
        FlowNode activityImpl = (FlowNode) bpmnModel.getMainProcess().getFlowElement(historicActivityInstances.get(i).getActivityId());
        <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 取出节点的所有出去的线，对所有的线进行遍历</span></span></span></span>
        List&lt;SequenceFlow&gt; pvmTransitions = activityImpl.getOutgoingFlows();
        <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">for</span></span></span></span> (SequenceFlow pvmTransition : pvmTransitions) {
            <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 获取节点</span></span></span></span>
            FlowNode pvmActivityImpl = (FlowNode) bpmnModel.getMainProcess().getFlowElement(pvmTransition.getTargetRef());

            <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 不是后继节点</span></span></span></span>
            <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">if</span></span></span></span>(!sameStartTimeNodes.contains(pvmActivityImpl)) <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">continue</span></span></span></span>;

            <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 如果取出的线的目标节点存在时间相同的节点里，保存该线的id，进行高亮显示</span></span></span></span>
            highFlows.add(pvmTransition.getId());
        }
    }

    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">//返回高亮的线</span></span></span></span>
    <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">return</span></span></span></span> highFlows;
}

<span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/**
 * &lt;p&gt;获取下一个节点信息&lt;/p&gt;
 * </span></span></span><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag">@param</span></span></span></span></span></span></span><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"> bpmnModel 流程模型
 * </span></span></span><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag">@param</span></span></span></span></span></span></span><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"> historicActivityInstances 历史节点
 * </span></span></span><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag">@param</span></span></span></span></span></span></span><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"> i 当前已经遍历到的历史节点索引（找下一个节点从此节点后）
 * </span></span></span><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag">@param</span></span></span></span></span></span></span><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"> activityImpl_ 当前遍历到的历史节点实例
 * </span></span></span><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag">@return</span></span></span></span></span></span></span><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"> FlowNode 下一个节点信息
 * </span></span></span><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag">@author</span></span></span></span></span></span></span><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"> FRH
 * </span></span></span><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag">@time</span></span></span></span></span></span></span><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"> 2018年12月10日上午11:26:55
 * </span></span></span><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag"><span class="hljs-comment"><span class="hljs-doctag">@version</span></span></span></span></span></span></span><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"> 1.0
 */</span></span></span></span>
<span class="hljs-function"><span class="hljs-keyword"><span class="hljs-function"><span class="hljs-keyword"><span class="hljs-function"><span class="hljs-keyword"><span class="hljs-function"><span class="hljs-keyword">private</span></span></span></span></span></span></span><span class="hljs-function"><span class="hljs-function"><span class="hljs-function"> </span></span></span><span class="hljs-keyword"><span class="hljs-function"><span class="hljs-keyword"><span class="hljs-function"><span class="hljs-keyword"><span class="hljs-function"><span class="hljs-keyword">static</span></span></span></span></span></span></span><span class="hljs-function"><span class="hljs-function"><span class="hljs-function"> FlowNode </span></span></span><span class="hljs-title"><span class="hljs-function"><span class="hljs-title"><span class="hljs-function"><span class="hljs-title"><span class="hljs-function"><span class="hljs-title">getNextFlowNode</span></span></span></span></span></span></span><span class="hljs-params"><span class="hljs-function"><span class="hljs-params"><span class="hljs-function"><span class="hljs-params"><span class="hljs-function"><span class="hljs-params">(BpmnModel bpmnModel, List&lt;HistoricActivityInstance&gt; historicActivityInstances, </span></span></span></span></span></span><span class="hljs-keyword"><span class="hljs-function"><span class="hljs-params"><span class="hljs-keyword"><span class="hljs-function"><span class="hljs-params"><span class="hljs-keyword"><span class="hljs-function"><span class="hljs-params"><span class="hljs-keyword">int</span></span></span></span></span></span></span></span></span></span><span class="hljs-function"><span class="hljs-params"><span class="hljs-function"><span class="hljs-params"><span class="hljs-function"><span class="hljs-params"> i, HistoricActivityInstance activityImpl_)</span></span></span></span></span></span></span><span class="hljs-function"><span class="hljs-function"><span class="hljs-function"> </span></span></span></span>{
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 保存后一个节点</span></span></span></span>
    FlowNode sameActivityImpl = <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">null</span></span></span></span>;

    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 如果当前节点不是用户任务节点，则取排序的下一个节点为后续节点</span></span></span></span>
    <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">if</span></span></span></span>(!<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"userTask"</span></span></span></span>.equals(activityImpl_.getActivityType())) {
        <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 是最后一个节点，没有下一个节点</span></span></span></span>
        <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">if</span></span></span></span>(i == historicActivityInstances.size()) <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">return</span></span></span></span> sameActivityImpl;
        <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 不是最后一个节点，取下一个节点为后继节点</span></span></span></span>
        sameActivityImpl = (FlowNode) bpmnModel.getMainProcess().getFlowElement(historicActivityInstances.get(i + <span class="hljs-number"><span class="hljs-number"><span class="hljs-number"><span class="hljs-number">1</span></span></span></span>).getActivityId());<span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 找到紧跟在后面的一个节点</span></span></span></span>
        <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 返回</span></span></span></span>
        <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">return</span></span></span></span> sameActivityImpl;
    }

    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 遍历后续节点，获取当前节点后续节点</span></span></span></span>
    <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">for</span></span></span></span> (<span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">int</span></span></span></span> k = i + <span class="hljs-number"><span class="hljs-number"><span class="hljs-number"><span class="hljs-number">1</span></span></span></span>; k &lt;= historicActivityInstances.size() - <span class="hljs-number"><span class="hljs-number"><span class="hljs-number"><span class="hljs-number">1</span></span></span></span>; k++) {
        <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 后续节点</span></span></span></span>
        HistoricActivityInstance activityImp2_ = historicActivityInstances.get(k);
        <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 都是userTask，且主节点与后续节点的开始时间相同，说明不是真实的后继节点</span></span></span></span>
        <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">if</span></span></span></span>(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"userTask"</span></span></span></span>.equals(activityImp2_.getActivityType()) &amp;&amp; activityImpl_.getStartTime().getTime() == activityImp2_.getStartTime().getTime()) <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">continue</span></span></span></span>;
        <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 找到紧跟在后面的一个节点</span></span></span></span>
        sameActivityImpl = (FlowNode) bpmnModel.getMainProcess().getFlowElement(historicActivityInstances.get(k).getActivityId());
        <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">break</span></span></span></span>;
    }
    <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">return</span></span></span></span> sameActivityImpl;
}

}

6.4 附上DemoController完整代码

package com.mypro.activiti.controller;

import java.io.InputStream;

import java.util.ArrayList;

import java.util.Date;

import java.util.HashMap;

import java.util.List;

import java.util.Map;

import java.util.stream.Collectors;

import javax.servlet.http.HttpServletRequest;

import javax.servlet.http.HttpServletResponse;

import org.activiti.bpmn.model.BpmnModel;

import org.activiti.engine.HistoryService;

import org.activiti.engine.RepositoryService;

import org.activiti.engine.RuntimeService;

import org.activiti.engine.TaskService;

import org.activiti.engine.history.HistoricActivityInstance;

import org.activiti.engine.history.HistoricActivityInstanceQuery;

import org.activiti.engine.history.HistoricProcessInstance;

import org.activiti.engine.impl.RepositoryServiceImpl;

import org.activiti.engine.impl.persistence.entity.ProcessDefinitionEntity;

import org.activiti.engine.runtime.ProcessInstance;

import org.activiti.engine.runtime.ProcessInstanceQuery;

import org.activiti.engine.task.Task;

import org.activiti.image.ProcessDiagramGenerator;

import org.apache.commons.lang3.StringUtils;

import org.slf4j.Logger;

import org.slf4j.LoggerFactory;

import org.springframework.beans.factory.annotation.Autowired;

import org.springframework.stereotype.Controller;

import org.springframework.web.bind.annotation.RequestMapping;

import org.springframework.web.bind.annotation.ResponseBody;

import com.mypro.activiti.utils.ActivitiUtils;

import com.mypro.activiti.utils.StreamUtils;

/**
<p>Activiti控制器</p>
@author FRH
@time 2018年12月10日上午9:30:18
@version 1.0

*/

@Controller

@RequestMapping("/demo")

public class DemoController {

private static final Logger logger = LoggerFactory.getLogger(DemoController.class);
<span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown">/</span></span></span></span></span></span><span class="hljs-emphasis"><span class="hljs-comment"><span class="markdown"><span class="hljs-emphasis"><span class="hljs-comment"><span class="markdown"><span class="hljs-emphasis"><span class="hljs-comment"><span class="markdown"><span class="hljs-emphasis">** 流程定义和部署相关的存储服务 *</span></span></span></span></span></span></span></span></span></span><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown">/</span></span></span></span></span></span></span></span>
<span class="hljs-meta"><span class="hljs-meta"><span class="hljs-meta"><span class="hljs-meta">@Autowired</span></span></span></span>
private RepositoryService repositoryService;

<span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown">/</span></span></span></span></span></span><span class="hljs-emphasis"><span class="hljs-comment"><span class="markdown"><span class="hljs-emphasis"><span class="hljs-comment"><span class="markdown"><span class="hljs-emphasis"><span class="hljs-comment"><span class="markdown"><span class="hljs-emphasis">** 流程运行时相关的服务 *</span></span></span></span></span></span></span></span></span></span><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown">/</span></span></span></span></span></span></span></span>
<span class="hljs-meta"><span class="hljs-meta"><span class="hljs-meta"><span class="hljs-meta">@Autowired</span></span></span></span>
private RuntimeService runtimeService;

<span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown">/</span></span></span></span></span></span><span class="hljs-emphasis"><span class="hljs-comment"><span class="markdown"><span class="hljs-emphasis"><span class="hljs-comment"><span class="markdown"><span class="hljs-emphasis"><span class="hljs-comment"><span class="markdown"><span class="hljs-emphasis">** 节点任务相关操作接口 *</span></span></span></span></span></span></span></span></span></span><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown">/</span></span></span></span></span></span></span></span>
<span class="hljs-meta"><span class="hljs-meta"><span class="hljs-meta"><span class="hljs-meta">@Autowired</span></span></span></span>
private TaskService taskService;

<span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown">/</span></span></span></span></span></span><span class="hljs-emphasis"><span class="hljs-comment"><span class="markdown"><span class="hljs-emphasis"><span class="hljs-comment"><span class="markdown"><span class="hljs-emphasis"><span class="hljs-comment"><span class="markdown"><span class="hljs-emphasis">** 流程图生成器 *</span></span></span></span></span></span></span></span></span></span><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown">/</span></span></span></span></span></span></span></span>
<span class="hljs-meta"><span class="hljs-meta"><span class="hljs-meta"><span class="hljs-meta">@Autowired</span></span></span></span>
private ProcessDiagramGenerator processDiagramGenerator;

<span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown">/</span></span></span></span></span></span><span class="hljs-emphasis"><span class="hljs-comment"><span class="markdown"><span class="hljs-emphasis"><span class="hljs-comment"><span class="markdown"><span class="hljs-emphasis"><span class="hljs-comment"><span class="markdown"><span class="hljs-emphasis">** 历史记录相关服务接口 *</span></span></span></span></span></span></span></span></span></span><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown">/</span></span></span></span></span></span></span></span>
<span class="hljs-meta"><span class="hljs-meta"><span class="hljs-meta"><span class="hljs-meta">@Autowired</span></span></span></span>
private HistoryService historyService;

<span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown">/**

* <p>跳转到测试主页面</p>

     * @return String 测试主页面

     * @author FRH

     * @time 2018年12月10日上午11:12:28

     * @version 1.0

     */

@RequestMapping(value="/toIndex.html")

public String toTestPage() {

return "/index";

}
<span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown">/**

* <p>跳转到上级审核页面</p>

     * @return String 上级审核页面

     * @author FRH

     * @time 2018年12月5日下午2:31:42

     * @version 1.0

     */

@RequestMapping(value="/toLeave")

public String employeeLeave() {

return "/employeeLeave";

}
<span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown">/**

* <p>启动请假流程（流程key即xml中定义的ID为leaveProcess）</p>

     * @return String 启动的流程ID

     * @author FRH

     * @time 2018年12月10日上午11:12:50

     * @version 1.0

     /

@RequestMapping(value="/start")

@ResponseBody

public String start() {

/

*  xml中定义的ID

*/

String instanceKey = "leaveProcess";

logger.info("开启请假流程...");
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     *  设置流程参数，开启流程
     */</span></span></span></span>
    <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">Map</span></span></span></span>&lt;<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">String</span></span></span></span>,<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">Object</span></span></span></span>&gt; map = <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">new</span></span></span></span> HashMap&lt;<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">String</span></span></span></span>,<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">Object</span></span></span></span>&gt;();
    map.put(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"jobNumber"</span></span></span></span>,<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"A1001"</span></span></span></span>);
    map.put(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"busData"</span></span></span></span>,<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"bus data"</span></span></span></span>);
    ProcessInstance instance = runtimeService.startProcessInstanceByKey(instanceKey, map);<span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">//使用流程定义的key启动流程实例，key对应helloworld.bpmn文件中id的属性值，使用key值启动，默认是按照最新版本的流程定义启动</span></span></span></span>

    logger.info(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"启动流程实例成功:{}"</span></span></span></span>, instance);
    logger.info(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"流程实例ID:{}"</span></span></span></span>, instance.getId());
    logger.info(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"流程定义ID:{}"</span></span></span></span>, instance.getProcessDefinitionId());

    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     * 验证是否启动成功
     */</span></span></span></span>
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">//通过查询正在运行的流程实例来判断</span></span></span></span>
    ProcessInstanceQuery processInstanceQuery = runtimeService.createProcessInstanceQuery();
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">//根据流程实例ID来查询</span></span></span></span>
    <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">List</span></span></span></span>&lt;ProcessInstance&gt; runningList = processInstanceQuery.processInstanceId(instance.getProcessInstanceId()).list();
    logger.info(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"根据流程ID查询条数:{}"</span></span></span></span>, runningList.size());

    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     *  返回流程ID
     */</span></span></span></span>
    <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">return</span></span></span></span> instance.getId();
}

<span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown">/**

* <p>查看当前流程图</p>

     * @param instanceId 流程实例

     * @param response void 响应

     * @author FRH

     * @time 2018年12月10日上午11:14:12

     * @version 1.0

     /

@ResponseBody

@RequestMapping(value="/showImg")

public void showImg(String instanceId, HttpServletResponse response) {

/

* 参数校验

*/

logger.info("查看完整流程图！流程实例ID:{}", instanceId);

if(StringUtils.isBlank(instanceId)) return;
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     *  获取流程实例
     */</span></span></span></span>
    HistoricProcessInstance processInstance = historyService.createHistoricProcessInstanceQuery().processInstanceId(instanceId).singleResult();
    <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">if</span></span></span></span>(processInstance == <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">null</span></span></span></span>) {
        logger.error(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"流程实例ID:{}没查询到流程实例！"</span></span></span></span>, instanceId);
        <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">return</span></span></span></span>;
    }

    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 根据流程对象获取流程对象模型</span></span></span></span>
    BpmnModel bpmnModel = repositoryService.getBpmnModel(processInstance.getProcessDefinitionId());

    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     *  查看已执行的节点集合
     *  获取流程历史中已执行节点，并按照节点在流程中执行先后顺序排序
     */</span></span></span></span>
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 构造历史流程查询</span></span></span></span>
    HistoricActivityInstanceQuery historyInstanceQuery = historyService.createHistoricActivityInstanceQuery().processInstanceId(instanceId);
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 查询历史节点</span></span></span></span>
    <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">List</span></span></span></span>&lt;HistoricActivityInstance&gt; historicActivityInstanceList = historyInstanceQuery.orderByHistoricActivityInstanceStartTime().asc().list();
    <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">if</span></span></span></span>(historicActivityInstanceList == <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">null</span></span></span></span> || historicActivityInstanceList.size() == <span class="hljs-number"><span class="hljs-number"><span class="hljs-number"><span class="hljs-number">0</span></span></span></span>) {
        logger.info(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"流程实例ID:{}没有历史节点信息！"</span></span></span></span>, instanceId);
        outputImg(response, bpmnModel, <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">null</span></span></span></span>, <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">null</span></span></span></span>);
        <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">return</span></span></span></span>;
    }
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 已执行的节点ID集合(将historicActivityInstanceList中元素的activityId字段取出封装到executedActivityIdList)</span></span></span></span>
    <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">List</span></span></span></span>&lt;<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">String</span></span></span></span>&gt; executedActivityIdList = historicActivityInstanceList.stream().map(item -&gt; item.getActivityId()).collect(Collectors.toList());

    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     *  获取流程走过的线
     */</span></span></span></span>
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">// 获取流程定义</span></span></span></span>
    ProcessDefinitionEntity processDefinition = (ProcessDefinitionEntity) ((RepositoryServiceImpl) repositoryService).getDeployedProcessDefinition(processInstance.getProcessDefinitionId());
    <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">List</span></span></span></span>&lt;<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">String</span></span></span></span>&gt; flowIds = ActivitiUtils.getHighLightedFlows(bpmnModel, processDefinition, historicActivityInstanceList);

    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     * 输出图像，并设置高亮
     */</span></span></span></span>
    outputImg(response, bpmnModel, flowIds, executedActivityIdList);
}

<span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown">/**

* <p>员工提交申请</p>

     * @param request 请求

     * @return String 申请受理结果

     * @author FRH

     * @time 2018年12月10日上午11:15:09

     * @version 1.0

     /

@RequestMapping(value="/employeeApply")

@ResponseBody

public String employeeApply(HttpServletRequest request){

/

* 获取请求参数

*/

String taskId = request.getParameter("taskId"); // 任务ID

String jobNumber = request.getParameter("jobNumber"); // 工号

String leaveDays = request.getParameter("leaveDays"); // 请假天数

String leaveReason = request.getParameter("leaveReason"); // 请假原因
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     *  查询任务
     */</span></span></span></span>
    Task task = taskService.createTaskQuery().taskId(taskId).singleResult();
    <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">if</span></span></span></span>(task == <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">null</span></span></span></span>) {
        logger.info(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"任务ID:{}查询到任务为空！"</span></span></span></span>, taskId);
        <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">return</span></span></span></span> <span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"fail"</span></span></span></span>;
    }

    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     * 参数传递并提交申请
     */</span></span></span></span>
    <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">Map</span></span></span></span>&lt;<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">String</span></span></span></span>, <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">Object</span></span></span></span>&gt; map = <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">new</span></span></span></span> HashMap&lt;<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">String</span></span></span></span>, <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">Object</span></span></span></span>&gt;();
    map.put(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"days"</span></span></span></span>, leaveDays);
    map.put(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"date"</span></span></span></span>, <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">new</span></span></span></span> Date());
    map.put(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"reason"</span></span></span></span>, leaveReason);
    map.put(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"jobNumber"</span></span></span></span>, jobNumber);
    taskService.complete(task.getId(), map);
    logger.info(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"执行【员工申请】环节，流程推动到【上级审核】环节"</span></span></span></span>);

    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     * 返回成功
     */</span></span></span></span>
    <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">return</span></span></span></span> <span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"success"</span></span></span></span>;
}

<span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown">/**

* <p>跳转到上级审核页面</p>

     * @return String 页面

     * @author FRH

     * @time 2018年12月5日下午2:31:42

     * @version 1.0

     /

@RequestMapping(value="/viewTask")

public String toHigherAudit(String taskId, HttpServletRequest request) {

/

* 获取参数

*/

logger.info("跳转到任务详情页面，任务ID:{}", taskId);

if(StringUtils.isBlank(taskId)) return "/higherAudit";
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     *  查看任务详细信息
     */</span></span></span></span>
    Task task = taskService.createTaskQuery().taskId(taskId).singleResult();
    <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">if</span></span></span></span>(task == <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">null</span></span></span></span>) {
        logger.info(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"任务ID:{}不存在！"</span></span></span></span>, taskId);
        <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">return</span></span></span></span> <span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"/higherAudit"</span></span></span></span>;
    }

    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     * 完成任务
     */</span></span></span></span>
    <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">Map</span></span></span></span>&lt;<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">String</span></span></span></span>, <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">Object</span></span></span></span>&gt; paramMap = taskService.getVariables(taskId);
    request.setAttribute(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"task"</span></span></span></span>, task);
    request.setAttribute(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"paramMap"</span></span></span></span>, paramMap);
    <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">return</span></span></span></span> <span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"higherAudit"</span></span></span></span>;
}

<span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown">/**

* <p>跳转到部门经理审核页面</p>

     * @param taskId 任务ID

     * @param request 请求

     * @return String 响应页面

     * @author FRH

     * @time 2018年12月6日上午9:54:34

     * @version 1.0

     /

@RequestMapping(value="/viewTaskManager")

public String viewTaskManager(String taskId, HttpServletRequest request) {

/

* 获取参数

*/

logger.info("跳转到任务详情页面，任务ID:{}", taskId);

if(StringUtils.isBlank(taskId)) return "/manageAudit";
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     *  查看任务详细信息
     */</span></span></span></span>
    Task task = taskService.createTaskQuery().taskId(taskId).singleResult();
    <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">if</span></span></span></span>(task == <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">null</span></span></span></span>) {
        logger.info(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"任务ID:{}不存在！"</span></span></span></span>, taskId);
        <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">return</span></span></span></span> <span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"/manageAudit"</span></span></span></span>;
    }

    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     * 完成任务
     */</span></span></span></span>
    <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">Map</span></span></span></span>&lt;<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">String</span></span></span></span>, <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">Object</span></span></span></span>&gt; paramMap = taskService.getVariables(taskId);
    request.setAttribute(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"task"</span></span></span></span>, task);
    request.setAttribute(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"paramMap"</span></span></span></span>, paramMap);
    <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">return</span></span></span></span> <span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"manageAudit"</span></span></span></span>;
}

<span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown">/**

* <p>上级审核</p>

     * @param request 请求

     * @return String 受理结果

     * @author FRH

     * @time 2018年12月10日上午11:19:44

     * @version 1.0

     /

@ResponseBody

@RequestMapping(value="/higherLevelAudit")

public String higherLevelAudit(HttpServletRequest request) {

/

* 获取请求参数

*/

String taskId = request.getParameter("taskId");

String higherLevelOpinion = request.getParameter("sug");

String auditStr = request.getParameter("audit");

logger.info("上级审核任务ID:{}", taskId);

if(StringUtils.isBlank(taskId)) return "fail";
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     * 查找任务
     */</span></span></span></span>
    Task task = taskService.createTaskQuery().taskId(taskId).singleResult();
    <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">if</span></span></span></span>(task == <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">null</span></span></span></span>) {
        logger.info(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"审核任务ID:{}查询到任务为空！"</span></span></span></span>, taskId);
        <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">return</span></span></span></span> <span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"fail"</span></span></span></span>;
    }

    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     * 设置局部变量参数，完成任务
     */</span></span></span></span>
    <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">Map</span></span></span></span>&lt;<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">String</span></span></span></span>, <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">Object</span></span></span></span>&gt; map = <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">new</span></span></span></span> HashMap&lt;<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">String</span></span></span></span>, <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">Object</span></span></span></span>&gt;();
    map.put(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"audit"</span></span></span></span>, <span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"1"</span></span></span></span>.equals(auditStr) ? <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">false</span></span></span></span> : <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">true</span></span></span></span>);
    map.put(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"higherLevelOpinion"</span></span></span></span>, higherLevelOpinion);
    taskService.complete(taskId, map);
    <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">return</span></span></span></span> <span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"success"</span></span></span></span>;
}

<span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown">/**

* <p>部门经理审核</p>

     * @param request 请求

     * @return String 受理结果

     * @author FRH

     * @time 2018年12月10日上午11:20:44

     * @version 1.0

     /

@ResponseBody

@RequestMapping(value="/divisionManagerAudit")

public String divisionManagerAudit(HttpServletRequest request) {

/

* 获取请求参数

*/

String taskId = request.getParameter("taskId");

String opinion = request.getParameter("sug");

String auditStr = request.getParameter("audit");

logger.info("上级审核任务ID:{}", taskId);

if(StringUtils.isBlank(taskId)) return "fail";
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     * 查找任务
     */</span></span></span></span>
    Task task = taskService.createTaskQuery().taskId(taskId).singleResult();
    <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">if</span></span></span></span>(task == <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">null</span></span></span></span>) {
        logger.info(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"审核任务ID:{}查询到任务为空！"</span></span></span></span>, taskId);
        <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">return</span></span></span></span> <span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"fail"</span></span></span></span>;
    }

    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     * 设置局部变量参数，完成任务
     */</span></span></span></span>
    <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">Map</span></span></span></span>&lt;<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">String</span></span></span></span>, <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">Object</span></span></span></span>&gt; map = <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">new</span></span></span></span> HashMap&lt;<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">String</span></span></span></span>, <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">Object</span></span></span></span>&gt;();
    map.put(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"audit"</span></span></span></span>, <span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"1"</span></span></span></span>.equals(auditStr) ? <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">false</span></span></span></span> : <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">true</span></span></span></span>);
    map.put(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"managerOpinion"</span></span></span></span>, opinion);
    taskService.complete(taskId, map);
    <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">return</span></span></span></span> <span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"success"</span></span></span></span>;
}

<span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown">/**

* <p>查看任务</p>

     * @param request 请求

     * @return String  任务展示页面

     * @author FRH

     * @time 2018年12月10日上午11:21:33

     * @version 1.0

     /

@RequestMapping(value="/toShowTask")

public String toShowTask(HttpServletRequest request) {

/

* 获取请求参数

*/

List<Task> taskList = taskService.createTaskQuery().list();

if(taskList == null || taskList.size() == 0) {

logger.info("查询任务列表为空！");

return "/task";

}
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     * 查询所有任务，并封装
     */</span></span></span></span>
    <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">List</span></span></span></span>&lt;<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">Map</span></span></span></span>&lt;<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">String</span></span></span></span>, <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">String</span></span></span></span>&gt;&gt; resultList = <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">new</span></span></span></span> ArrayList&lt;<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">Map</span></span></span></span>&lt;<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">String</span></span></span></span>, <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">String</span></span></span></span>&gt;&gt;();
    <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">for</span></span></span></span>(Task task : taskList) {
        <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">Map</span></span></span></span>&lt;<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">String</span></span></span></span>, <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">String</span></span></span></span>&gt; map = <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">new</span></span></span></span> HashMap&lt;<span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">String</span></span></span></span>, <span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in"><span class="hljs-built_in">String</span></span></span></span>&gt;();
        map.put(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"taskId"</span></span></span></span>, task.getId());
        map.put(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"name"</span></span></span></span>, task.getName());
        map.put(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"createTime"</span></span></span></span>, task.getCreateTime().toString());
        map.put(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"assignee"</span></span></span></span>, task.getAssignee());
        map.put(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"instanceId"</span></span></span></span>, task.getProcessInstanceId());
        map.put(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"executionId"</span></span></span></span>, task.getExecutionId());
        map.put(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"definitionId"</span></span></span></span>, task.getProcessDefinitionId());
        resultList.add(map);
    }

    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">/*
     * 返回结果
     */</span></span></span></span>
    logger.info(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"返回集合:{}"</span></span></span></span>, resultList.toString());
    request.setAttribute(<span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"resultList"</span></span></span></span>, resultList);
    <span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword"><span class="hljs-keyword">return</span></span></span></span> <span class="hljs-string"><span class="hljs-string"><span class="hljs-string"><span class="hljs-string">"/task"</span></span></span></span>;
}

<span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown">/**

* <p>输出图像</p>

     * @param response 响应实体

     * @param bpmnModel 图像对象

     * @param flowIds 已执行的线集合

     * @param executedActivityIdList void 已执行的节点ID集合

     * @author FRH

     * @time 2018年12月10日上午11:23:01

     * @version 1.0

     */

private void outputImg(HttpServletResponse response, BpmnModel bpmnModel, List<String> flowIds, List<String> executedActivityIdList) {

InputStream imageStream = null;

try {

imageStream = processDiagramGenerator.generateDiagram(bpmnModel, executedActivityIdList, flowIds, "宋体", "微软雅黑", "黑体", true, "png");

// 输出资源内容到相应对象

byte[] b = new byte[1024];

int len;

while ((len = imageStream.read(b, 0, 1024)) != -1) {

response.getOutputStream().write(b, 0, len);

}

response.getOutputStream().flush();

}catch(Exception e) {

logger.error("流程图输出异常！", e);

} finally { // 流关闭

StreamUtils.closeInputStream(imageStream);

}

}
<span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown"><span class="hljs-comment"><span class="markdown">/**

* <p>判断流程是否完成</p>

     * @param processInstanceId 流程实例ID

     * @return boolean 已完成-true，未完成-false

     * @author FRH

     * @time 2018年12月10日上午11:23:26

     * @version 1.0

     */

public boolean isFinished(String processInstanceId) {

return historyService.createHistoricProcessInstanceQuery().finished().processInstanceId(processInstanceId).count() > 0;

}
}

7. 效果

    看出Activiti默认使用Spring的security，添加配置，关闭安全认证，如下：

# 关闭activiti登录验证
security:
  basic:
    enabled: false

    重启后继续访问，可正常进入首页（如还是无法进入首页，请添加@EnableAutoConfiguration(exclude = {org.springframework.boot.autoconfigure.security.servlet.SecurityAutoConfiguration.class})，或者从pom.xml中移除Security包）：



    点击我要请假后，得到流程实例ID，再查看流程图，如下：

    附上首页/index.html代码，其它页面相比比较简单：

<!DOCTYPE html>
<html xmlns="http://www.w3.org/1999/xhtml" xmlns:th="http://www.thymeleaf.org">
<head>
    <meta http-equiv="Content-Type" content="text/html; charset=UTF-8">
    <meta name="viewport" content="width=device-width, initial-scale=1">
    <title>首页</title>
    <script th:src="@{/static/jquery.min.js}"></script>
    <script type="text/javascript">
        $(function(){
            // 点击菜单
            $(".show-page").bind("click", function(){
                $(".main-body").html("");
                $(".result-div").html("");
                var url = $(this).attr("url");
            $.ajax({
                </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">async</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal">false</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
                </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">cache</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal">false</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
                </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">type</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">'POST'</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
                </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">url</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : url,
                </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">dataType</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"html"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
                </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">error</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword">function</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">(</span></span></span></span></span></span><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span>) </span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">{
                    alert(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">'请求失败'</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">);
                },
                </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">success</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword">function</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">(</span></span></span></span></span></span><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params">data</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">) </span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">{
                    $(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">".result-div"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">).html(data);
                }
            });
        });

        </span></span></span><span class="hljs-comment"><span class="javascript"><span class="hljs-comment"><span class="javascript"><span class="hljs-comment"><span class="javascript"><span class="hljs-comment">// 点击我要请假，开启流程</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">
        $(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">".show-instance"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">).bind(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"click"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">, </span></span></span><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword">function</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">(</span></span></span></span></span></span><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span>)</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">{
            $(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">".main-body"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">).html(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">""</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">);
            $(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">".result-div"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">).html(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">""</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">);
            </span></span></span><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword">var</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> url = $(</span></span></span><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword">this</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">).attr(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"url"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">);

            $.ajax({
                </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">async</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal">false</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
                </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">cache</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal">false</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
                </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">type</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">'POST'</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
                </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">url</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : url,
                </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">dataType</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"html"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
                </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">error</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword">function</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">(</span></span></span></span></span></span><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span>) </span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">{
                    alert(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">'请求失败'</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">);
                },
                </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">success</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword">function</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">(</span></span></span></span></span></span><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params">data</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">) </span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">{
                    $(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"input[name='instanceId']"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">).val(data);
                }
            });
        });

        </span></span></span><span class="hljs-comment"><span class="javascript"><span class="hljs-comment"><span class="javascript"><span class="hljs-comment"><span class="javascript"><span class="hljs-comment">// 绑定查看流程图</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">
        $(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">".show-img"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">).bind(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"click"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">, </span></span></span><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword">function</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">(</span></span></span></span></span></span><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span>)</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">{
            </span></span></span><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword">var</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> instanceId = $(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"input[name='instanceId']"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">).val();
            </span></span></span><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword">if</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">(instanceId == </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">""</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">) {
                alert(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"暂无流程！"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">);
                </span></span></span><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword">return</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">;
            }
            </span></span></span><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword">var</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> imgHtml = </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">'&lt;embed src="/demo/showImg?instanceId='</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> + instanceId + </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">'" style="display:block;width:1000px;height:450px" /&gt;'</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">;
            $(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">".result-div"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">).html(imgHtml);
        });

        </span></span></span><span class="hljs-comment"><span class="javascript"><span class="hljs-comment"><span class="javascript"><span class="hljs-comment"><span class="javascript"><span class="hljs-comment">// 查看任务</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">
        $(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">".show-task"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">).bind(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"click"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">, </span></span></span><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword">function</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">(</span></span></span></span></span></span><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span>)</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">{
            $.ajax({
                </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">async</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal">false</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
                </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">cache</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal">false</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
                </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">type</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">'POST'</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
                </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">url</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"/demo/toShowTask"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
                </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">data</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : {</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"aaabbbccc"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">:</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"aa"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">},
                </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">dataType</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"html"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
                </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">error</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword">function</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">(</span></span></span></span></span></span><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span>) </span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">{
                    alert(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">'请求失败'</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">);
                },
                </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">success</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword">function</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">(</span></span></span></span></span></span><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params">data</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">) </span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">{
                    $(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">".result-div"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">).html(data);
                }
            });
        });

    });

    </span></span></span><span class="hljs-comment"><span class="javascript"><span class="hljs-comment"><span class="javascript"><span class="hljs-comment"><span class="javascript"><span class="hljs-comment">/**
     * 员工提交申请
     */</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">
    </span></span></span><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword">function</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"> </span></span></span></span></span></span><span class="hljs-title"><span class="javascript"><span class="hljs-function"><span class="hljs-title"><span class="javascript"><span class="hljs-function"><span class="hljs-title"><span class="javascript"><span class="hljs-function"><span class="hljs-title">toLeave</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">(</span></span></span></span></span></span><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span>) </span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">{
        $.ajax({
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">async</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal">false</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">cache</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal">false</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">type</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">'POST'</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">url</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"/demo/employeeApply"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">dataType</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">: </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"text"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">data</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">: $(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">".employee-leave"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">).serialize(),
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">error</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword">function</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">(</span></span></span></span></span></span><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span>) </span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">{
                alert(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">'请求失败'</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">);
            },
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">success</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword">function</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">(</span></span></span></span></span></span><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params">data</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">) </span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">{
                alert(data);
            }
        });
    }

    </span></span></span><span class="hljs-comment"><span class="javascript"><span class="hljs-comment"><span class="javascript"><span class="hljs-comment"><span class="javascript"><span class="hljs-comment">/**
     * 上级审核
     */</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">
    </span></span></span><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword">function</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"> </span></span></span></span></span></span><span class="hljs-title"><span class="javascript"><span class="hljs-function"><span class="hljs-title"><span class="javascript"><span class="hljs-function"><span class="hljs-title"><span class="javascript"><span class="hljs-function"><span class="hljs-title">higherAudit</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">(</span></span></span></span></span></span><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span>) </span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">{
        $.ajax({
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">async</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal">false</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">cache</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal">false</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">type</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">'POST'</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">url</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"/demo/higherLevelAudit"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">dataType</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">: </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"text"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">data</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">: $(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">".higher-audit"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">).serialize(),
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">error</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword">function</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">(</span></span></span></span></span></span><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span>) </span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">{
                alert(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">'请求失败'</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">);
            },
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">success</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword">function</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">(</span></span></span></span></span></span><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params">data</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">) </span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">{
                alert(data);
            }
        });
    }

    </span></span></span><span class="hljs-comment"><span class="javascript"><span class="hljs-comment"><span class="javascript"><span class="hljs-comment"><span class="javascript"><span class="hljs-comment">/**
     * 部门经理审核
     */</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">
    </span></span></span><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword">function</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"> </span></span></span></span></span></span><span class="hljs-title"><span class="javascript"><span class="hljs-function"><span class="hljs-title"><span class="javascript"><span class="hljs-function"><span class="hljs-title"><span class="javascript"><span class="hljs-function"><span class="hljs-title">managerAudit</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">(</span></span></span></span></span></span><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span>) </span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">{
        $.ajax({
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">async</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal">false</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">cache</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal">false</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">type</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">'POST'</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">url</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"/demo/divisionManagerAudit"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">dataType</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">: </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"text"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">data</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">: $(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">".manager-audit"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">).serialize(),
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">error</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword">function</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">(</span></span></span></span></span></span><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span>) </span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">{
                alert(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">'请求失败'</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">);
            },
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">success</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword">function</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">(</span></span></span></span></span></span><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params">data</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">) </span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">{
                alert(data);
            }
        });
    }

    </span></span></span><span class="hljs-comment"><span class="javascript"><span class="hljs-comment"><span class="javascript"><span class="hljs-comment"><span class="javascript"><span class="hljs-comment">/**
     * 上级审核
     */</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">
    </span></span></span><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword">function</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"> </span></span></span></span></span></span><span class="hljs-title"><span class="javascript"><span class="hljs-function"><span class="hljs-title"><span class="javascript"><span class="hljs-function"><span class="hljs-title"><span class="javascript"><span class="hljs-function"><span class="hljs-title">viewTask</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">(</span></span></span></span></span></span><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params">taskId, name</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">) </span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">{
        </span></span></span><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword">var</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> url = </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"/demo/viewTask"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">;
        </span></span></span><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword"><span class="javascript"><span class="hljs-keyword">if</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">(name != </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"上级审核"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">) {
            url = </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"/demo/viewTaskManager"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">;
        }

        $.ajax({
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">async</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal">false</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">cache</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal"><span class="javascript"><span class="hljs-literal">false</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">type</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">'POST'</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">url</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : url,
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">data</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : {</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"taskId"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : taskId},
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">dataType</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">"html"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">,
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">error</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword">function</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">(</span></span></span></span></span></span><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span><span class="javascript"><span class="hljs-function"><span class="hljs-params"></span>) </span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">{
                alert(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">'请求失败'</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">);
            },
            </span></span></span><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr"><span class="javascript"><span class="hljs-attr">success</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript"> : </span></span></span><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword"><span class="javascript"><span class="hljs-function"><span class="hljs-keyword">function</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">(</span></span></span></span></span></span><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params"><span class="javascript"><span class="hljs-function"><span class="hljs-params">data</span></span></span></span></span></span></span></span></span></span><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function"><span class="javascript"><span class="hljs-function">) </span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">{
                $(</span></span></span><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string"><span class="javascript"><span class="hljs-string">".result-div"</span></span></span></span></span></span></span><span class="javascript"><span class="javascript"><span class="javascript">).html(data);
            }
        });
    }
</span></span></span></span><span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag">&lt;/</span></span></span><span class="hljs-name"><span class="hljs-tag"><span class="hljs-name"><span class="hljs-tag"><span class="hljs-name"><span class="hljs-tag"><span class="hljs-name">script</span></span></span></span></span></span></span><span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag">&gt;</span></span></span></span>

</head>

<body>

<!-- 菜单栏 -->

<div class="main-menu">

<button class="show-instance" url="/demo/start">我要请假</button>

<button class="show-page" url="/demo/toLeave">开始填单</button>

<button class="show-img">查看流程图</button>

<button class="show-task">查看任务</button>

</div>

<br/>

流程实例ID:<input type="text" name="instanceId"/>

<br/>

<!-- 操作栏 -->

<div class="main-body">
<span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag">&lt;/</span></span></span><span class="hljs-name"><span class="hljs-tag"><span class="hljs-name"><span class="hljs-tag"><span class="hljs-name"><span class="hljs-tag"><span class="hljs-name">div</span></span></span></span></span></span></span><span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag">&gt;</span></span></span></span>
<span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag">&lt;</span></span></span><span class="hljs-name"><span class="hljs-tag"><span class="hljs-name"><span class="hljs-tag"><span class="hljs-name"><span class="hljs-tag"><span class="hljs-name">br</span></span></span></span></span></span></span><span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag">/&gt;</span></span></span></span>
<span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">&lt;!-- 结果栏 --&gt;</span></span></span></span>
<span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag">&lt;</span></span></span><span class="hljs-name"><span class="hljs-tag"><span class="hljs-name"><span class="hljs-tag"><span class="hljs-name"><span class="hljs-tag"><span class="hljs-name">div</span></span></span></span></span></span></span><span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag"> </span></span></span><span class="hljs-attr"><span class="hljs-tag"><span class="hljs-attr"><span class="hljs-tag"><span class="hljs-attr"><span class="hljs-tag"><span class="hljs-attr">class</span></span></span></span></span></span></span><span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag">=</span></span></span><span class="hljs-string"><span class="hljs-tag"><span class="hljs-string"><span class="hljs-tag"><span class="hljs-string"><span class="hljs-tag"><span class="hljs-string">"result-div"</span></span></span></span></span></span></span><span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag">&gt;</span></span></span></span>
    <span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag">&lt;</span></span></span><span class="hljs-name"><span class="hljs-tag"><span class="hljs-name"><span class="hljs-tag"><span class="hljs-name"><span class="hljs-tag"><span class="hljs-name">embed</span></span></span></span></span></span></span><span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag"> </span></span></span><span class="hljs-attr"><span class="hljs-tag"><span class="hljs-attr"><span class="hljs-tag"><span class="hljs-attr"><span class="hljs-tag"><span class="hljs-attr">src</span></span></span></span></span></span></span><span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag">=</span></span></span><span class="hljs-string"><span class="hljs-tag"><span class="hljs-string"><span class="hljs-tag"><span class="hljs-string"><span class="hljs-tag"><span class="hljs-string">"/demo/showImg?instanceId=5070fd58-f859-11e8-a359-484d7ec5762d"</span></span></span></span></span></span></span><span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag"> </span></span></span><span class="hljs-attr"><span class="hljs-tag"><span class="hljs-attr"><span class="hljs-tag"><span class="hljs-attr"><span class="hljs-tag"><span class="hljs-attr">style</span></span></span></span></span></span></span><span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag">=</span></span></span><span class="hljs-string"><span class="hljs-tag"><span class="hljs-string"><span class="hljs-tag"><span class="hljs-string"><span class="hljs-tag"><span class="hljs-string">"display:block;width:1000px;height:450px"</span></span></span></span></span></span></span><span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag"> /&gt;</span></span></span></span>
    <span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag">&lt;</span></span></span><span class="hljs-name"><span class="hljs-tag"><span class="hljs-name"><span class="hljs-tag"><span class="hljs-name"><span class="hljs-tag"><span class="hljs-name">br</span></span></span></span></span></span></span><span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag">&gt;</span></span></span></span>
    <span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment"><span class="hljs-comment">&lt;!-- &lt;img src="/static/leave-process.png"/&gt; --&gt;</span></span></span></span>
<span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag">&lt;/</span></span></span><span class="hljs-name"><span class="hljs-tag"><span class="hljs-name"><span class="hljs-tag"><span class="hljs-name"><span class="hljs-tag"><span class="hljs-name">div</span></span></span></span></span></span></span><span class="hljs-tag"><span class="hljs-tag"><span class="hljs-tag">&gt;</span></span></span></span>

</body>

</html>

      </div>

原文地址：https://blog.csdn.net/qq_40451631/article/details/84937251
