SpringBoot整合RabbitMq(二)

       本文序列化和添加package参考：https://www.jianshu.com/p/13fd9ff0648d

RabbitMq安装

[root@topcheer ~]# docker images
REPOSITORY                TAG                 IMAGE ID            CREATED             SIZE
elasticsearch             latest              874179f19603        11 days ago         771 MB
springbootdemo4docker     latest              cd13bc7f56a0        2 weeks ago         678 MB
docker.io/tomcat          latest              ee48881b3e82        4 weeks ago         506 MB
docker.io/rabbitmq        latest              a00bc560660a        4 weeks ago         147 MB
docker.io/centos          latest              67fa590cfc1c        7 weeks ago         202 MB
docker.io/redis           latest              f7302e4ab3a8        8 weeks ago         98.2 MB
docker.io/rabbitmq        3.7.16-management   3f92e6354d11        2 months ago        177 MB
[root@topcheer ~]# docker run -d -p 5672:5672  -p 15672:15672 --name myrabbitmq 3f92e6354d11
ab8a0c8bae576f12ff334b22aae36d5fd87e744062462765628b06b5a65b9005
[root@topcheer ~]# docker ps -l
CONTAINER ID        IMAGE               COMMAND                  CREATED             STATUS              PORTS                                                                                        NAMES
ab8a0c8bae57        3f92e6354d11        "docker-entrypoint..."   27 seconds ago      Up 26 seconds       4369/tcp, 5671/tcp, 0.0.0.0:5672->5672/tcp, 15671/tcp, 25672/tcp, 0.0.0.0:15672->15672/tcp   myrabbitmq
[root@topcheer ~]#

账号密码都为guest,创建交换机

进行交换机和队列进行绑定

Springboot开发

 <dependencies>
         <!--消息队列依赖-->
         <dependency>
             <groupId>org.springframework.boot</groupId>
             <artifactId>spring-boot-starter-amqp</artifactId>
         </dependency>
         <!--web相关依赖-->
         <dependency>
             <groupId>org.springframework.boot</groupId>
             <artifactId>spring-boot-starter-web</artifactId>
         </dependency>
         <!--fastjson依赖-->
         <dependency>
             <groupId>com.alibaba</groupId>
             <artifactId>fastjson</artifactId>
             <version>1.2.44</version>
         </dependency>
         <!--lombok依赖-->
         <dependency>
             <groupId>org.projectlombok</groupId>
             <artifactId>lombok</artifactId>
             <optional>true</optional>
         </dependency>
         <!--测试依赖-->
         <dependency>
             <groupId>org.springframework.boot</groupId>
             <artifactId>spring-boot-starter-test</artifactId>
             <scope>test</scope>
         </dependency>

启动类

 /**
  * 自动配置
  *  1、RabbitAutoConfiguration
  *  2、有自动配置了连接工厂ConnectionFactory；
  *  3、RabbitProperties 封装了 RabbitMQ的配置
  *  4、 RabbitTemplate ：给RabbitMQ发送和接受消息；
  *  5、 AmqpAdmin ： RabbitMQ系统管理功能组件;
  *      AmqpAdmin：创建和删除 Queue，Exchange，Binding
  *  6、@EnableRabbit +  @RabbitListener 监听消息队列的内容
  *
  */
 @MapperScan("com.topcheer.*.*.dao")
 @SpringBootApplication
 @EnableCaching
 @EnableRabbit
 public class Oss6Application {
 ​
     public static void main(String[] args) {
         SpringApplication.run(Oss6Application.class, args);
     }
 ​
 }

配置文件

 spring:
   rabbitmq:
     host: 192.168.180.113
     username: guest
     password: guest

Bo类

 /**
  * @author WGR
  * @create 2019/9/3 -- 0:34
  */
 @Document(indexName = "topcheer",type = "book" )
 @Slf4j
 @Data
 //@Builder  用这个来构造，反序列化的时候会出问题
 public class Book implements Serializable {
 ​
     private Integer id;
     private String name;
     private String author;

     public Book(String name, String author) {
         this.name = name;
         this.author = author;
     }
 ​
     public Book(Integer id, String name, String author) {
         this.id = id;
         this.name = name;
         this.author = author;
     }
 ​
     public Book() {
     }
 }

MessageConverter

我们先来创建一个转换的实现类，只需要继承抽象类AbstractMessageConverter并实现内部的createMessage、fromMessage两个方法就可以完成实体类的序列化与反序列化的转换，代码如下所示：

 /**
  * 自定义消息转换器
  * 采用FastJson完成消息转换
  *
  * @author：于起宇 <br/>
  * ===============================
  * Created with Eclipse.
  * Date：2017/10/26
  * Time：19:28
  * 简书：http://www.jianshu.com/u/092df3f77bca
  * ================================
  */
 public class RabbitMqFastJsonConverter
         extends AbstractMessageConverter {
     /**
      * 日志对象实例
      */
     private Logger logger = LoggerFactory.getLogger(RabbitMqFastJsonConverter.class);
     /**
      * 消息类型映射对象
      */
     private static ClassMapper classMapper = new DefaultClassMapper();
     /**
      * 默认字符集
      */
     private static String DEFAULT_CHART_SET = "UTF-8";
 ​
     /**
      * 创建消息
      *
      * @param o                 消息对象
      * @param messageProperties 消息属性
      * @return
      */
     @Override
     protected Message createMessage(Object o, MessageProperties messageProperties) {
         byte[] bytes = null;
         try {
             String jsonString = JSON.toJSONString(o);
             bytes = jsonString.getBytes(DEFAULT_CHART_SET);
         } catch (IOException e) {
             throw new MessageConversionException(
                     "Failed to convert Message content", e);
         }
         messageProperties.setContentType(MessageProperties.CONTENT_TYPE_JSON);
         messageProperties.setContentEncoding(DEFAULT_CHART_SET);
         if (bytes != null) {
             messageProperties.setContentLength(bytes.length);
         }
         classMapper.fromClass(o.getClass(), messageProperties);
         return new Message(bytes, messageProperties);
     }
 ​
     /**
      * 转换消息为对象
      *
      * @param message 消息对象
      * @return
      * @throws MessageConversionException
      */
     @Override
     public Object fromMessage(Message message) throws MessageConversionException {
         Object content = null;
         MessageProperties properties = message.getMessageProperties();
         if (properties != null) {
             String contentType = properties.getContentType();
             if (contentType != null && contentType.contains("json")) {
                 String encoding = properties.getContentEncoding();
                 if (encoding == null) {
                     encoding = DEFAULT_CHART_SET;
                 }
                 try {
                     Class<?> targetClass = classMapper.toClass(
                             message.getMessageProperties());
 ​
                     content = convertBytesToObject(message.getBody(),
                             encoding, targetClass);
                 } catch (IOException e) {
                     throw new MessageConversionException(
                             "Failed to convert Message content", e);
                 }
             } else {
                 logger.warn("Could not convert incoming message with content-type ["
                         + contentType + "]");
             }
         }
         if (content == null) {
             content = message.getBody();
         }
         return content;
     }
 ​
     /**
      * 将字节数组转换成实例对象
      *
      * @param body     Message对象主体字节数组
      * @param encoding 字符集
      * @param clazz    类型
      * @return
      * @throws UnsupportedEncodingException
      */
     private Object convertBytesToObject(byte[] body, String encoding,
                                         Class<?> clazz) throws UnsupportedEncodingException {
         String contentAsString = new String(body, encoding);
         return JSON.parseObject(contentAsString, clazz);
     }
 }
 在该转换类内我们使用了DefaultClassMapper来作为类的映射，我们可以先来看下该类相关信任package的源码，如下所示：

 ......
 public class DefaultClassMapper implements ClassMapper, InitializingBean {
     public static final String DEFAULT_CLASSID_FIELD_NAME = "__TypeId__";
     private static final String DEFAULT_HASHTABLE_TYPE_ID = "Hashtable";
     // 默认信任的package列表
     private static final List<String> TRUSTED_PACKAGES = Arrays.asList("java.util", "java.lang");
     private final Set<String> trustedPackages;
     private volatile Map<String, Class<?>> idClassMapping;
     private volatile Map<Class<?>, String> classIdMapping;
     private volatile Class<?> defaultMapClass;
     private volatile Class<?> defaultType;
 ​
     public DefaultClassMapper() {
         // 构造函数初始化信任的package为默认的pakcage列表
         // 仅支持java.util、java.lang两个package
         this.trustedPackages = new LinkedHashSet(TRUSTED_PACKAGES);
         this.idClassMapping = new HashMap();
         this.classIdMapping = new HashMap();
         this.defaultMapClass = LinkedHashMap.class;
         this.defaultType = LinkedHashMap.class;
     }
 ......

RabbitMqConfiguration

下面我们需要将该转换设置到RabbitTemplate、SimpleRabbitListenerContainerFactory内，让RabbitMQ支持自定义的消息转换，如下所示：

 /**
  * rabbitmq 相关配置
  * @author：于起宇 <br/>
  * ===============================
  * Created with IDEA.
  * Date：2018/3/11
  * Time：下午5:42
  * 简书：http://www.jianshu.com/u/092df3f77bca
  * ================================
  */
 @Configuration
 public class RabbitMqConfiguration {
 ​
 ​
     /**
      * 配置消息队列模版
      * 并且设置MessageConverter为自定义FastJson转换器
      * @param connectionFactory
      * @return
      */
     @Bean
     public RabbitTemplate rabbitTemplate(ConnectionFactory connectionFactory) {
         RabbitTemplate template = new RabbitTemplate(connectionFactory);
         template.setMessageConverter(new RabbitMqFastJsonConverter());
         return template;
     }
 ​
     /**
      * 自定义队列容器工厂
      * 并且设置MessageConverter为自定义FastJson转换器
      * @param connectionFactory
      * @return
      */
     @Bean
     public SimpleRabbitListenerContainerFactory rabbitListenerContainerFactory(ConnectionFactory connectionFactory) {
         SimpleRabbitListenerContainerFactory factory = new SimpleRabbitListenerContainerFactory();
         factory.setConnectionFactory(connectionFactory);
         factory.setMessageConverter(new RabbitMqFastJsonConverter());
         factory.setDefaultRequeueRejected(false);
         return factory;
     }
 ​
 }

重写DefaultClassMapper构造函数

不加这个会报错，显示这个类没有被信任

创建一个名为RabbitMqFastJsonClassMapper的类并且继承DefaultClassMapper，如下所示：

 /**
  * fastjson 转换映射
  *
  * @author：于起宇 <br/>
  * ===============================
  * Created with IDEA.
  * Date：2018/3/13
  * Time：下午10:17
  * 简书：http://www.jianshu.com/u/092df3f77bca
  * ================================
  */
 public class RabbitMqFastJsonClassMapper extends DefaultClassMapper {
     /**
      * 构造函数初始化信任所有pakcage
      */
     public RabbitMqFastJsonClassMapper() {
         super();
         setTrustedPackages("*");
     }
 }

在上面构造函数内我们设置了信任全部的package，添加了RabbitMqFastJsonClassMapper类后，需要让MessageConverter使用该类作为映射，修改RabbitMqFastJsonConverter部分代码如下所示：

/**
 * 消息类型映射对象
 */
private static ClassMapper classMapper = new DefaultClassMapper();
>>> 修改为 >>>
/**
* 消息类型映射对象
*/
private static ClassMapper classMapper = new RabbitMqFastJsonClassMapper();

监听类

 @Service
 public class BookService {
 ​
     @RabbitListener(queues = "topcheer.news")
     public void receive(Book book){
         System.out.println("收到消息："+book);
     }
 ​
     @RabbitListener(queues = "topcheer")
     public void receive02(Message message){
         System.out.println(message.getBody());
         System.out.println(message.getMessageProperties());
     }
 }
 ​

测试类

​


   /**
      * 1、单播（点对点）
      */
     @Test
     public void contextLoads() {
         //Message需要自己构造一个;定义消息体内容和消息头
         //rabbitTemplate.send(exchage,routeKey,message);
 ​
         //object默认当成消息体，只需要传入要发送的对象，自动序列化发送给rabbitmq；
         //rabbitTemplate.convertAndSend(exchage,routeKey,object);
         Map<String,Object> map = new HashMap<>();
         map.put("msg","这是第一个消息");
         map.put("data", Arrays.asList("helloworld",123,true));
         //对象被默认序列化以后发送出去
         rabbitTemplate.convertAndSend("exchange-direct","topcheer",new Book("红楼梦","曹雪芹"));
 ​
     }
 ​
     //接受数据,如何将数据自动的转为json发送出去
     @Test
     public void receive(){
         Object o = rabbitTemplate.receiveAndConvert("topcheer.news");
        // System.out.println(o.getClass());
         System.out.println(o);
     }
 ​
     /**
      * 广播
      */
     @Test
     public void sendMsg(){
        rabbitTemplate.convertAndSend("exchange-fanout","",new Book("红楼梦1","曹雪芹1"));
     }

测试结果如下：

2019-10-11 22:20:50.730  INFO --- [           main] tMqFastJsonConverter : 消息为对象
Book(id=null, name=红楼梦, author=曹雪芹)

2019-10-11 22:39:04.284  INFO --- [ntContainer#1-1] tMqFastJsonConverter : 消息为对象
[B@4da0a5ae
MessageProperties [headers={__TypeId__=com.topcheer.oss.shiro.bo.Book}, contentType=application/json, contentEncoding=UTF-8, contentLength=0, receivedDeliveryMode=PERSISTENT, priority=0, redelivered=false, receivedExchange=exchange-direct, receivedRoutingKey=topcheer, deliveryTag=4, consumerTag=amq.ctag-mFGYgGzoHK3Utt8uk2Hxdg, consumerQueue=topcheer]
​
