adf笔记

1>jsf页面js调试，手动添加debugger调试

方案：在页面中添加debugger,然后打开“开发者工具”（必须打开），直接运行页面自动跳转到debugger处。

2>jdeveloper使用svn版本控制，修改后版本控制异常

方案：使用jdeveloper集成的svn版本进行控制，经常出现版本控制异常，比如修改了几个问题，查看版本变动的时候

发现以前添加的文件都没有版本了，方法重新启动jdeveloper

3>jdeveloper使用svn版本控制,修改文件后查看挂起的更改，发现没有记录

方案：打开任意一个jdeveloper中的项目，然后再查看挂起的更改。

4>jdeveloper开发过程中，调试和运行可能突然中断，然后点击页面运行或调试，进入页面后直接卡死，紧接着weblogic直接终止运行或调试。

再次运行或是调试，weblgici始终无法启动，

方案：run>start server instance，先运行weblogci,然后再选择页面点击运行

5>无法验证事务处理中的所有行

运行项目报错：

javax.faces.el.EvaluationException: oracle.jbo.TxnValException: JBO-27023: 无法验证事务处理中的所有行。

出错原因：提交的字段的值没有通过验证
比如说：字段的长度过长，类型不匹配
注意：如果对数据库中的字段做修改，要与eo同步更改。

6>jdeveloper快捷键

ctrl+enter：输入sop然后按ctrl+enter，输出 System.out.println()

ctrl+enter：直接输入ctrl+enter,出来流程控制的智能提示

ctrl+j：删除本行

shift+enter：换行

ctrl+shift+上下方向键：向上或向下移动当前行代码

ctrl+shift+空格键：上下文智能提示

shift+alt+f：格式化

7>通用类ADFUtils和JSFUtils

 package view;

 import java.util.ArrayList;
 import java.util.List;

 import javax.faces.model.SelectItem;

 import oracle.adf.model.BindingContext;
 import oracle.adf.model.binding.DCBindingContainer;
 import oracle.adf.model.binding.DCIteratorBinding;
 import oracle.adf.model.binding.DCParameter;

 import oracle.adf.share.logging.ADFLogger;

 import oracle.binding.AttributeBinding;
 import oracle.binding.BindingContainer;

 import oracle.binding.ControlBinding;

 import oracle.binding.OperationBinding;

 import oracle.jbo.ApplicationModule;
 import oracle.jbo.Key;
 import oracle.jbo.Row;
 import oracle.jbo.uicli.binding.JUCtrlValueBinding;

 /**
  * A series of convenience functions for dealing with ADF Bindings.
  * Note: Updated for JDeveloper 11
  *
  * @author Duncan Mills
  * @author Steve Muench
  *
  * $Id: ADFUtils.java 2513 2007-09-20 20:39:13Z ralsmith $.
  */
 public class ADFUtils {

     public static final ADFLogger LOGGER = ADFLogger.createADFLogger(ADFUtils.class);

     /**
      * Get application module for an application module data control by name.
      * @param name application module data control name
      * @return ApplicationModule
      */
     public static ApplicationModule getApplicationModuleForDataControl(String name) {
         return (ApplicationModule)JSFUtils.resolveExpression("#{data." + name +
                                                              ".dataProvider}");
     }

     /**
      * A convenience method for getting the value of a bound attribute in the
      * current page context programatically.
      * @param attributeName of the bound value in the pageDef
      * @return value of the attribute
      */
     public static Object getBoundAttributeValue(String attributeName) {
         return findControlBinding(attributeName).getInputValue();
     }

     /**
      * A convenience method for setting the value of a bound attribute in the
      * context of the current page.
      * @param attributeName of the bound value in the pageDef
      * @param value to set
      */
     public static void setBoundAttributeValue(String attributeName,
                                               Object value) {
         findControlBinding(attributeName).setInputValue(value);
     }

     /**
      * Returns the evaluated value of a pageDef parameter.
      * @param pageDefName reference to the page definition file of the page with the parameter
      * @param parameterName name of the pagedef parameter
      * @return evaluated value of the parameter as a String
      */
     public static Object getPageDefParameterValue(String pageDefName,
                                                   String parameterName) {
         BindingContainer bindings = findBindingContainer(pageDefName);
         DCParameter param =
             ((DCBindingContainer)bindings).findParameter(parameterName);
         return param.getValue();
     }

     /**
      * Convenience method to find a DCControlBinding as an AttributeBinding
      * to get able to then call getInputValue() or setInputValue() on it.
      * @param bindingContainer binding container
      * @param attributeName name of the attribute binding.
      * @return the control value binding with the name passed in.
      *
      */
     public static AttributeBinding findControlBinding(BindingContainer bindingContainer,
                                                       String attributeName) {
         if (attributeName != null) {
             if (bindingContainer != null) {
                 ControlBinding ctrlBinding =
                     bindingContainer.getControlBinding(attributeName);
                 if (ctrlBinding instanceof AttributeBinding) {
                     return (AttributeBinding)ctrlBinding;
                 }
             }
         }
         return null;
     }

     /**
      * Convenience method to find a DCControlBinding as a JUCtrlValueBinding
      * to get able to then call getInputValue() or setInputValue() on it.
      * @param attributeName name of the attribute binding.
      * @return the control value binding with the name passed in.
      *
      */
     public static AttributeBinding findControlBinding(String attributeName) {
         return findControlBinding(getBindingContainer(), attributeName);
     }

     /**
      * Return the current page's binding container.
      * @return the current page's binding container
      */
     public static BindingContainer getBindingContainer() {
         return (BindingContainer)JSFUtils.resolveExpression("#{bindings}");
     }

     /**
      * Return the Binding Container as a DCBindingContainer.
      * @return current binding container as a DCBindingContainer
      */
     public static DCBindingContainer getDCBindingContainer() {
         return (DCBindingContainer)getBindingContainer();
     }

     /**
      * Get List of ADF Faces SelectItem for an iterator binding.
      *
      * Uses the value of the 'valueAttrName' attribute as the key for
      * the SelectItem key.
      *
      * @param iteratorName ADF iterator binding name
      * @param valueAttrName name of the value attribute to use
      * @param displayAttrName name of the attribute from iterator rows to display
      * @return ADF Faces SelectItem for an iterator binding
      */
     public static List<SelectItem> selectItemsForIterator(String iteratorName,
                                                           String valueAttrName,
                                                           String displayAttrName) {
         return selectItemsForIterator(findIterator(iteratorName),
                                       valueAttrName, displayAttrName);
     }

     /**
      * Get List of ADF Faces SelectItem for an iterator binding with description.
      *
      * Uses the value of the 'valueAttrName' attribute as the key for
      * the SelectItem key.
      *
      * @param iteratorName ADF iterator binding name
      * @param valueAttrName name of the value attribute to use
      * @param displayAttrName name of the attribute from iterator rows to display
      * @param descriptionAttrName name of the attribute to use for description
      * @return ADF Faces SelectItem for an iterator binding with description
      */
     public static List<SelectItem> selectItemsForIterator(String iteratorName,
                                                           String valueAttrName,
                                                           String displayAttrName,
                                                           String descriptionAttrName) {
         return selectItemsForIterator(findIterator(iteratorName),
                                       valueAttrName, displayAttrName,
                                       descriptionAttrName);
     }

     /**
      * Get List of attribute values for an iterator.
      * @param iteratorName ADF iterator binding name
      * @param valueAttrName value attribute to use
      * @return List of attribute values for an iterator
      */
     public static List attributeListForIterator(String iteratorName,
                                                 String valueAttrName) {
         return attributeListForIterator(findIterator(iteratorName),
                                         valueAttrName);
     }

     /**
      * Get List of Key objects for rows in an iterator.
      * @param iteratorName iterabot binding name
      * @return List of Key objects for rows
      */
     public static List<Key> keyListForIterator(String iteratorName) {
         return keyListForIterator(findIterator(iteratorName));
     }

     /**
      * Get List of Key objects for rows in an iterator.
      * @param iter iterator binding
      * @return List of Key objects for rows
      */
     public static List<Key> keyListForIterator(DCIteratorBinding iter) {
         List<Key> attributeList = new ArrayList<Key>();
         for (Row r : iter.getAllRowsInRange()) {
             attributeList.add(r.getKey());
         }
         return attributeList;
     }

     /**
      * Get List of Key objects for rows in an iterator using key attribute.
      * @param iteratorName iterator binding name
      * @param keyAttrName name of key attribute to use
      * @return List of Key objects for rows
      */
     public static List<Key> keyAttrListForIterator(String iteratorName,
                                                    String keyAttrName) {
         return keyAttrListForIterator(findIterator(iteratorName), keyAttrName);
     }

     /**
      * Get List of Key objects for rows in an iterator using key attribute.
      *
      * @param iter iterator binding
      * @param keyAttrName name of key attribute to use
      * @return List of Key objects for rows
      */
     public static List<Key> keyAttrListForIterator(DCIteratorBinding iter,
                                                    String keyAttrName) {
         List<Key> attributeList = new ArrayList<Key>();
         for (Row r : iter.getAllRowsInRange()) {
             attributeList.add(new Key(new Object[] { r.getAttribute(keyAttrName) }));
         }
         return attributeList;
     }

     /**
      * Get a List of attribute values for an iterator.
      *
      * @param iter iterator binding
      * @param valueAttrName name of value attribute to use
      * @return List of attribute values
      */
     public static List attributeListForIterator(DCIteratorBinding iter,
                                                 String valueAttrName) {
         List attributeList = new ArrayList();
         for (Row r : iter.getAllRowsInRange()) {
             attributeList.add(r.getAttribute(valueAttrName));
         }
         return attributeList;
     }

     /**
      * Find an iterator binding in the current binding container by name.
      *
      * @param name iterator binding name
      * @return iterator binding
      */
     public static DCIteratorBinding findIterator(String name) {
         DCIteratorBinding iter =
             getDCBindingContainer().findIteratorBinding(name);
         if (iter == null) {
             throw new RuntimeException("Iterator '" + name + "' not found");
         }
         return iter;
     }

     /**
      * @param bindingContainer
      * @param iterator
      * @return
      */
     public static DCIteratorBinding findIterator(String bindingContainer, String iterator) {
         DCBindingContainer bindings =
             (DCBindingContainer)JSFUtils.resolveExpression("#{" + bindingContainer + "}");
         if (bindings == null) {
             throw new RuntimeException("Binding container '" +
                                        bindingContainer + "' not found");
         }
         DCIteratorBinding iter = bindings.findIteratorBinding(iterator);
         if (iter == null) {
             throw new RuntimeException("Iterator '" + iterator + "' not found");
         }
         return iter;
     }

     /**
      * @param name
      * @return
      */
     public static JUCtrlValueBinding findCtrlBinding(String name){
         JUCtrlValueBinding rowBinding =
             (JUCtrlValueBinding)getDCBindingContainer().findCtrlBinding(name);
         if (rowBinding == null) {
             throw new RuntimeException("CtrlBinding " + name + "' not found");
         }
         return rowBinding;
     }

     /**
      * Find an operation binding in the current binding container by name.
      *
      * @param name operation binding name
      * @return operation binding
      */
     public static OperationBinding findOperation(String name) {
         OperationBinding op =
             getDCBindingContainer().getOperationBinding(name);
         if (op == null) {
             throw new RuntimeException("Operation '" + name + "' not found");
         }
         return op;
     }

     /**
      * Find an operation binding in the current binding container by name.
      *
      * @param bindingContianer binding container name
      * @param opName operation binding name
      * @return operation binding
      */
     public static OperationBinding findOperation(String bindingContianer,
                                                  String opName) {
         DCBindingContainer bindings =
             (DCBindingContainer)JSFUtils.resolveExpression("#{" + bindingContianer + "}");
         if (bindings == null) {
             throw new RuntimeException("Binding container '" +
                                        bindingContianer + "' not found");
         }
         OperationBinding op =
             bindings.getOperationBinding(opName);
         if (op == null) {
             throw new RuntimeException("Operation '" + opName + "' not found");
         }
         return op;
     }

     /**
      * Get List of ADF Faces SelectItem for an iterator binding with description.
      *
      * Uses the value of the 'valueAttrName' attribute as the key for
      * the SelectItem key.
      *
      * @param iter ADF iterator binding
      * @param valueAttrName name of value attribute to use for key
      * @param displayAttrName name of the attribute from iterator rows to display
      * @param descriptionAttrName name of the attribute for description
      * @return ADF Faces SelectItem for an iterator binding with description
      */
     public static List<SelectItem> selectItemsForIterator(DCIteratorBinding iter,
                                                           String valueAttrName,
                                                           String displayAttrName,
                                                           String descriptionAttrName) {
         List<SelectItem> selectItems = new ArrayList<SelectItem>();
         for (Row r : iter.getAllRowsInRange()) {
             selectItems.add(new SelectItem(r.getAttribute(valueAttrName),
                                            (String)r.getAttribute(displayAttrName),
                                            (String)r.getAttribute(descriptionAttrName)));
         }
         return selectItems;
     }

     /**
      * Get List of ADF Faces SelectItem for an iterator binding.
      *
      * Uses the value of the 'valueAttrName' attribute as the key for
      * the SelectItem key.
      *
      * @param iter ADF iterator binding
      * @param valueAttrName name of value attribute to use for key
      * @param displayAttrName name of the attribute from iterator rows to display
      * @return ADF Faces SelectItem for an iterator binding
      */
     public static List<SelectItem> selectItemsForIterator(DCIteratorBinding iter,
                                                           String valueAttrName,
                                                           String displayAttrName) {
         List<SelectItem> selectItems = new ArrayList<SelectItem>();
         for (Row r : iter.getAllRowsInRange()) {
             selectItems.add(new SelectItem(r.getAttribute(valueAttrName),
                                            (String)r.getAttribute(displayAttrName)));
         }
         return selectItems;
     }

     /**
      * Get List of ADF Faces SelectItem for an iterator binding.
      *
      * Uses the rowKey of each row as the SelectItem key.
      *
      * @param iteratorName ADF iterator binding name
      * @param displayAttrName name of the attribute from iterator rows to display
      * @return ADF Faces SelectItem for an iterator binding
      */
     public static List<SelectItem> selectItemsByKeyForIterator(String iteratorName,
                                                                String displayAttrName) {
         return selectItemsByKeyForIterator(findIterator(iteratorName),
                                            displayAttrName);
     }

     /**
      * Get List of ADF Faces SelectItem for an iterator binding with discription.
      *
      * Uses the rowKey of each row as the SelectItem key.
      *
      * @param iteratorName ADF iterator binding name
      * @param displayAttrName name of the attribute from iterator rows to display
      * @param descriptionAttrName name of the attribute for description
      * @return ADF Faces SelectItem for an iterator binding with discription
      */
     public static List<SelectItem> selectItemsByKeyForIterator(String iteratorName,
                                                                String displayAttrName,
                                                                String descriptionAttrName) {
         return selectItemsByKeyForIterator(findIterator(iteratorName),
                                            displayAttrName,
                                            descriptionAttrName);
     }

     /**
      * Get List of ADF Faces SelectItem for an iterator binding with discription.
      *
      * Uses the rowKey of each row as the SelectItem key.
      *
      * @param iter ADF iterator binding
      * @param displayAttrName name of the attribute from iterator rows to display
      * @param descriptionAttrName name of the attribute for description
      * @return ADF Faces SelectItem for an iterator binding with discription
      */
     public static List<SelectItem> selectItemsByKeyForIterator(DCIteratorBinding iter,
                                                                String displayAttrName,
                                                                String descriptionAttrName) {
         List<SelectItem> selectItems = new ArrayList<SelectItem>();
         for (Row r : iter.getAllRowsInRange()) {
             selectItems.add(new SelectItem(r.getKey(),
                                            (String)r.getAttribute(displayAttrName),
                                            (String)r.getAttribute(descriptionAttrName)));
         }
         return selectItems;
     }

     /**
      * Get List of ADF Faces SelectItem for an iterator binding.
      *
      * Uses the rowKey of each row as the SelectItem key.
      *
      * @param iter ADF iterator binding
      * @param displayAttrName name of the attribute from iterator rows to display
      * @return List of ADF Faces SelectItem for an iterator binding
      */
     public static List<SelectItem> selectItemsByKeyForIterator(DCIteratorBinding iter,
                                                                String displayAttrName) {
         List<SelectItem> selectItems = new ArrayList<SelectItem>();
         for (Row r : iter.getAllRowsInRange()) {
             selectItems.add(new SelectItem(r.getKey(),
                                            (String)r.getAttribute(displayAttrName)));
         }
         return selectItems;
     }

     /**
      * Find the BindingContainer for a page definition by name.
      *
      * Typically used to refer eagerly to page definition parameters. It is
      * not best practice to reference or set bindings in binding containers
      * that are not the one for the current page.
      *
      * @param pageDefName name of the page defintion XML file to use
      * @return BindingContainer ref for the named definition
      */
     private static BindingContainer findBindingContainer(String pageDefName) {
         BindingContext bctx = getDCBindingContainer().getBindingContext();
         BindingContainer foundContainer =
             bctx.findBindingContainer(pageDefName);
         return foundContainer;
     }

     /**
      * @param opList
      */
     public static void printOperationBindingExceptions(List opList){
         if(opList != null && !opList.isEmpty()){
             for(Object error:opList){
                 LOGGER.severe( error.toString() );
             }
         }
     }
 }

ADFUtils

 package view;

 import java.util.Iterator;
 import java.util.Locale;
 import java.util.Map;
 import java.util.MissingResourceException;
 import java.util.ResourceBundle;

 import javax.el.ELContext;
 import javax.el.ExpressionFactory;

 import javax.el.MethodExpression;
 import javax.el.ValueExpression;

 import javax.faces.application.Application;
 import javax.faces.application.FacesMessage;
 import javax.faces.component.UIComponent;
 import javax.faces.component.UIViewRoot;
 import javax.faces.context.ExternalContext;
 import javax.faces.context.FacesContext;

 import javax.servlet.http.HttpServletRequest;

 /**
  * General useful static utilies for working with JSF.
  * NOTE: Updated to use JSF 1.2 ExpressionFactory.
  *
  * @author Duncan Mills
  * @author Steve Muench
  *
  * $Id: JSFUtils.java 1885 2007-06-26 00:47:41Z ralsmith $
  */
 public class JSFUtils {

     private static final String NO_RESOURCE_FOUND = "Missing resource: ";

     /**
      * Method for taking a reference to a JSF binding expression and returning
      * the matching object (or creating it).
      * @param expression EL expression
      * @return Managed object
      */
     public static Object resolveExpression(String expression) {
         FacesContext facesContext = getFacesContext();
         Application app = facesContext.getApplication();
         ExpressionFactory elFactory = app.getExpressionFactory();
         ELContext elContext = facesContext.getELContext();
         ValueExpression valueExp =
             elFactory.createValueExpression(elContext, expression,
                                             Object.class);
         return valueExp.getValue(elContext);
     }

     /**
      * @return
      */
     public static String resolveRemoteUser() {
         FacesContext facesContext = getFacesContext();
         ExternalContext ectx = facesContext.getExternalContext();
         return ectx.getRemoteUser();
     }

     /**
      * @return
      */
     public static String resolveUserPrincipal() {
         FacesContext facesContext = getFacesContext();
         ExternalContext ectx = facesContext.getExternalContext();
         HttpServletRequest request = (HttpServletRequest)ectx.getRequest();
         return request.getUserPrincipal().getName();
     }

     /**
      * @param expression
      * @param returnType
      * @param argTypes
      * @param argValues
      * @return
      */
     public static Object resolveMethodExpression(String expression,
                                                  Class returnType,
                                                  Class[] argTypes,
                                                  Object[] argValues) {
         FacesContext facesContext = getFacesContext();
         Application app = facesContext.getApplication();
         ExpressionFactory elFactory = app.getExpressionFactory();
         ELContext elContext = facesContext.getELContext();
         MethodExpression methodExpression =
             elFactory.createMethodExpression(elContext, expression, returnType,
                                              argTypes);
         return methodExpression.invoke(elContext, argValues);
     }

     /**
      * Method for taking a reference to a JSF binding expression and returning
      * the matching Boolean.
      * @param expression EL expression
      * @return Managed object
      */
     public static Boolean resolveExpressionAsBoolean(String expression) {
         return (Boolean)resolveExpression(expression);
     }

     /**
      * Method for taking a reference to a JSF binding expression and returning
      * the matching String (or creating it).
      * @param expression EL expression
      * @return Managed object
      */
     public static String resolveExpressionAsString(String expression) {
         return (String)resolveExpression(expression);
     }

     /**
      * Convenience method for resolving a reference to a managed bean by name
      * rather than by expression.
      * @param beanName name of managed bean
      * @return Managed object
      */
     public static Object getManagedBeanValue(String beanName) {
         StringBuffer buff = new StringBuffer("#{");
         buff.append(beanName);
         buff.append("}");
         return resolveExpression(buff.toString());
     }

     /**
      * Method for setting a new object into a JSF managed bean
      * Note: will fail silently if the supplied object does
      * not match the type of the managed bean.
      * @param expression EL expression
      * @param newValue new value to set
      */
     public static void setExpressionValue(String expression, Object newValue) {
         FacesContext facesContext = getFacesContext();
         Application app = facesContext.getApplication();
         ExpressionFactory elFactory = app.getExpressionFactory();
         ELContext elContext = facesContext.getELContext();
         ValueExpression valueExp =
             elFactory.createValueExpression(elContext, expression,
                                             Object.class);

         //Check that the input newValue can be cast to the property type
         //expected by the managed bean.
         //If the managed Bean expects a primitive we rely on Auto-Unboxing
         Class bindClass = valueExp.getType(elContext);
         if (bindClass.isPrimitive() || bindClass.isInstance(newValue)) {
             valueExp.setValue(elContext, newValue);
         }
     }

     /**
      * Convenience method for setting the value of a managed bean by name
      * rather than by expression.
      * @param beanName name of managed bean
      * @param newValue new value to set
      */
     public static void setManagedBeanValue(String beanName, Object newValue) {
         StringBuffer buff = new StringBuffer("#{");
         buff.append(beanName);
         buff.append("}");
         setExpressionValue(buff.toString(), newValue);
     }

     /**
      * Convenience method for setting Session variables.
      * @param key object key
      * @param object value to store
      */
     public static

     void storeOnSession(String key, Object object) {
         FacesContext ctx = getFacesContext();
         Map sessionState = ctx.getExternalContext().getSessionMap();
         sessionState.put(key, object);
     }

     /**
      * Convenience method for getting Session variables.
      * @param key object key
      * @return session object for key
      */
     public static Object getFromSession(String key) {
         FacesContext ctx = getFacesContext();
         Map sessionState = ctx.getExternalContext().getSessionMap();
         return sessionState.get(key);
     }

     /**
      * @param key
      * @return
      */
     public static String getFromHeader(String key) {
         FacesContext ctx = getFacesContext();
         ExternalContext ectx = ctx.getExternalContext();
         return ectx.getRequestHeaderMap().get(key);
     }

     /**
      * Convenience method for getting Request variables.
      * @param key object key
      * @return session object for key
      */
     public static Object getFromRequest(String key) {
         FacesContext ctx = getFacesContext();
         Map sessionState = ctx.getExternalContext().getRequestMap();
         return sessionState.get(key);
     }

     /**
      * Pulls a String resource from the property bundle that
      * is defined under the application <message-bundle> element in
      * the faces config. Respects Locale
      * @param key string message key
      * @return Resource value or placeholder error String
      */
     public static String getStringFromBundle(String key) {
         ResourceBundle bundle = getBundle();
         return getStringSafely(bundle, key, null);
     }

     /**
      * Convenience method to construct a <code>FacesMesssage</code>
      * from a defined error key and severity
      * This assumes that the error keys follow the convention of
      * using <b>_detail</b> for the detailed part of the
      * message, otherwise the main message is returned for the
      * detail as well.
      * @param key for the error message in the resource bundle
      * @param severity severity of message
      * @return Faces Message object
      */
     public static FacesMessage getMessageFromBundle(String key,
                                                     FacesMessage.Severity severity) {
         ResourceBundle bundle = getBundle();
         String summary = getStringSafely(bundle, key, null);
         String detail = getStringSafely(bundle, key + "_detail", summary);
         FacesMessage message = new FacesMessage(summary, detail);
         message.setSeverity(severity);
         return message;
     }

     /**
      * Add JSF info message.
      * @param msg info message string
      */
     public static void addFacesInformationMessage(String msg) {
         FacesContext ctx = getFacesContext();
         FacesMessage fm =
             new FacesMessage(FacesMessage.SEVERITY_INFO, msg, "");
         ctx.addMessage(getRootViewComponentId(), fm);
     }

     /**
      * Add JSF error message.
      * @param msg error message string
      */
     public static void addFacesErrorMessage(String msg) {
         FacesContext ctx = getFacesContext();
         FacesMessage fm =
             new FacesMessage(FacesMessage.SEVERITY_ERROR, msg, "");
         ctx.addMessage(getRootViewComponentId(), fm);
     }

     /**
      * Add JSF error message for a specific attribute.
      * @param attrName name of attribute
      * @param msg error message string
      */
     public static void addFacesErrorMessage(String attrName, String msg) {
         FacesContext ctx = getFacesContext();
         FacesMessage fm =
             new FacesMessage(FacesMessage.SEVERITY_ERROR, attrName, msg);
         ctx.addMessage(getRootViewComponentId(), fm);
     }

     // Informational getters

     /**
      * Get view id of the view root.
      * @return view id of the view root
      */
     public static String getRootViewId() {
         return getFacesContext().getViewRoot().getViewId();
     }

     /**
      * Get component id of the view root.
      * @return component id of the view root
      */
     public static String getRootViewComponentId() {
         return getFacesContext().getViewRoot().getId();
     }

     /**
      * Get FacesContext.
      * @return FacesContext
      */
     public static FacesContext getFacesContext() {
         return FacesContext.getCurrentInstance();
     }
     /*
    * Internal method to pull out the correct local
    * message bundle
    */

     private static ResourceBundle getBundle() {
         FacesContext ctx = getFacesContext();
         UIViewRoot uiRoot = ctx.getViewRoot();
         Locale locale = uiRoot.getLocale();
         ClassLoader ldr = Thread.currentThread().getContextClassLoader();
         return ResourceBundle.getBundle(ctx.getApplication().getMessageBundle(),
                                         locale, ldr);
     }

     /**
      * Get an HTTP Request attribute.
      * @param name attribute name
      * @return attribute value
      */
     public static Object getRequestAttribute(String name) {
         return getFacesContext().getExternalContext().getRequestMap().get(name);
     }

     /**
      * Set an HTTP Request attribute.
      * @param name attribute name
      * @param value attribute value
      */
     public static void setRequestAttribute(String name, Object value) {
         getFacesContext().getExternalContext().getRequestMap().put(name,
                                                                    value);
     }

     /*
    * Internal method to proxy for resource keys that don't exist
    */

     private static String getStringSafely(ResourceBundle bundle, String key,
                                           String defaultValue) {
         String resource = null;
         try {
             resource = bundle.getString(key);
         } catch (MissingResourceException mrex) {
             if (defaultValue != null) {
                 resource = defaultValue;
             } else {
                 resource = NO_RESOURCE_FOUND + key;
             }
         }
         return resource;
     }

     /**
      * Locate an UIComponent in view root with its component id. Use a recursive way to achieve this.
      * @param id UIComponent id
      * @return UIComponent object
      */
     public static UIComponent findComponentInRoot(String id) {
         UIComponent component = null;
         FacesContext facesContext = FacesContext.getCurrentInstance();
         if (facesContext != null) {
             UIComponent root = facesContext.getViewRoot();
             component = findComponent(root, id);
         }
         return component;
     }

     /**
      * Locate an UIComponent from its root component.
      * Taken from http://www.jroller.com/page/mert?entry=how_to_find_a_uicomponent
      * @param base root Component (parent)
      * @param id UIComponent id
      * @return UIComponent object
      */
     public static UIComponent findComponent(UIComponent base, String id) {
         if (id.equals(base.getId()))
             return base;

         UIComponent children = null;
         UIComponent result = null;
         Iterator childrens = base.getFacetsAndChildren();
         while (childrens.hasNext() && (result == null)) {
             children = (UIComponent)childrens.next();
             if (id.equals(children.getId())) {
                 result = children;
                 break;
             }
             result = findComponent(children, id);
             if (result != null) {
                 break;
             }
         }
         return result;
     }

     /**
      * Method to create a redirect URL. The assumption is that the JSF servlet mapping is
      * "faces", which is the default
      *
      * @param view the JSP or JSPX page to redirect to
      * @return a URL to redirect to
      */
     public static String getPageURL(String view) {
         FacesContext facesContext = getFacesContext();
         ExternalContext externalContext = facesContext.getExternalContext();
         String url =
             ((HttpServletRequest)externalContext.getRequest()).getRequestURL().toString();
         StringBuffer newUrlBuffer = new StringBuffer();
         newUrlBuffer.append(url.substring(0, url.lastIndexOf("faces/")));
         newUrlBuffer.append("faces");
         String targetPageUrl = view.startsWith("/") ? view : "/" + view;
         newUrlBuffer.append(targetPageUrl);
         return newUrlBuffer.toString();
     }

     public static boolean isPostBack(){
         return JSFUtils.resolveExpressionAsBoolean("#{adfFacesContext.postback}");
         }

 }

JSFUtils

8>在jsf页面绑定的Managed Bean中引用am

在bean中获取am，在对应的jsf页面中必须有注册，否则返回空

ADFUtils.getApplicationModuleForDataControl("AppModuleAMDataControl");

9>jsf页面跳转，十一adf的link标签,设置destination属性

<af:link text="link 1" destination="" id="l1"/>

程序员的基础教程：菜鸟程序员
